I Series IC-15A Temperature Control Module
Quick Start Manual
Page 3 of 5 12/02/2013
INCOE
®
Corp. Global Headquarters 1740 E. Maple Road Troy, Mi 48083 USA T: 248-616-0220 E: tech.support@incoe.com www.incoe.com
OPERATION
Basic Functions
▲ / ▼
Adjust Set Value (SV)
SET
Select unit digit for ▲ and ▼
SEL + 1 sec. Exit IDLE (IdL) after power on
SEL + 1 sec.
Change to next method of operation -
Auto / Standby / Manual
MODE
Changes SV display -
Set Temperature / Output % / Amps
(Automatic Operation only)
MODE + SEL + 1 sec. Initiate Boost Feature
MODE + 3 sec. Access Settings Menu
MODE + SET + 5 sec. Access Conguration Menu
MODE + SET
Save value - 5 seconds without a button
push will also save
Error Codes
Error Code Display Description
1 FU-1 Fuse 1 Disconnection
2 FU-2 Fuse 2 Disconnection
3 tCoP Thermocouple Disconnection
4 tCSt Thermocouple Short-Circuit
5 tCrE Thermocouple Polarity Reverse
6 AL-H High Limit Temperature Alarm
7 AL-L Low Limit Temperature Alarm
8 HtoP Heater Disconnection (Low Current)
9 HtSt Heater Short (High Current)
10 trSt Triac Short
Menu Navigation
MODE
Next Menu option
▲ / ▼
Adjust numeric values
SET
Select unit digit for ▲ and ▼
SET
Change non-numeric values
(e.g., °C or °F)
MODE + SET
Save value - 5 seconds without a button
push will also save
