Tank Setup Page 2 - 5
2
Tanks – TANK ALARM N Menu (C
ONTINUED
...
FROM
PREVIOUS
PA G E
)
LL LIM OG N (assign Alarm Limits to Output Group)
L L PRODUCT OUTPUT GROUP N (32 OGs available... see Worksheet #2 or #3)
NONE
Not assigned to an output Group (OG)
GROUP A-FF One OG selected (
A = 1
ST
OG, FF = 32
ND OG
)
ALL GROUPS All OGs selected
Use
UP/DOWN
▲ ▼ keys to choose an OG.
Press
ENTER
to accept this data.
WATER LIM N
HIGH WATER LEVEL LIMIT N
+4.0000
0.0 to 9999.0 (enter alarm limit)
Press
ENTER
to accept this data.
W LIM OG N (assign Alarm Limits to Output Group)
HIGH WATER OUTPUT GROUP N (32 OGs available... see Worksheet #2 or #3)
NONE
Not assigned to an output Group (OG)
GROUP A-FF One OG selected (
A = 1
ST
OG, FF = 32
ND OG
)
ALL GROUPS All OGs selected
Use
UP/DOWN
▲ ▼ keys to choose an OG.
Press
ENTER
to accept this data.
WATER LIM N and W LIM OG N are not available for PRESSURE probes, since they do
not measure water level.
Tanks – SPECIAL TANK N Menu
• If
STANDARD tanks
are selcted, then these menu options will not be available.
• Correction Tables:
If the Special Tank is not a perfect cylinder or has a domed end,
then you must program a correction table (100 correction points can be programmed).
Two values are required per point / position (POS #). These are level and volume, which
are found in the manufacturers’ tank table /chart, input these accurately. Always input 0
level and 0 volume for the first point, and max. level and max. volume for the last point.
The number of points in between determines the accuracy of the strapping table.
• Cylindrical Tanks:
Select diameter and input the internal tank diameter value, and
set the length to the internal length of the tank (correction tables are usually not needed
with cylindrical tanks).
• Vertical or Rectangular tanks:
Select diameter and input the internal tank diameter or
depth, and set its
length
to zero
( 0 )
. Input 0 level and 0 volume for the first point, and
max. level and max. volume for the last point.
• Correction Points
are automatically sorted from lowest to highest level. The lowest
level is closest to the bottom of the tank.
SPECIAL
SPECIAL TANKS
SPECIAL 1
SPECIAL 2
: Use
UP
/
DOWN
▲▼ keys to display tanks 5-8.
SPECIAL 8
NOTE
☞
NOTE
☞
To Next Page
