Probes Setup Page 4 - 1
4
4 Probes SETUP PROGRAMMING
Probes Menu
H U
MENU
× Press this key and follow the
7
highlighted sequence below
NOTE
☞
See the Installation Guide – Chapters 6 & 7 for
Probe Model & Serial numbers, Gradient values,
Float types, and RTD Locations).
Only the NO. (of) TANKS programmed under
the system menu are shown here !
Remember:
• Use ▲
UP
or
DOWN
▼ key to display more
menus or selections (MORE or UP/DN
shown)
• Press
CANCEL
to cancel data entry
• Use the
ENTER
key to accept data
Character input / editing:
• Press
M4
to backspace (delete) one
character to the left
ï
• Use
M2
to move the cursor right
ð
• Press
M1
to move the cursor left
ï
N refers to / represents any probe #
PROBE DATA Press (
M
) key to select probe # for setup.
PROBE
1
PROBE 2 Press
UP/DOWN
▲
▼ keys to display
: probes 5 – 8 (for TS-2001/508 only).
PROBE 8
PROBE DATA N (Optional - used to copy probe data)
COPY Press
M1
key.
COPY FROM PROBE DATA X TO N Press (
M
) key to select a probe # to copy.
PROBE 1
PROBE 2 Press
UP/DOWN
▲
▼ keys to display
: probes 5 – 8 (for TS-2001/508 only).
PROBE 8
COPY FROM PROBE DATA X TO N
PRESS ENTER IF YOU ARE SURE? Press
ENTER
to accept this data.
See the Table of Contents to find topics in
this manual. See the Preface for general
information about this manual. And see the
Installation, Operator’s, TroubleShooting
Guides, and Application Notes for other
reference material.
Contents:
Probes Menu
Probe Data Menu
Special Probes Menu
TABLE 4.1 Special Probe RTD
Positions
SELECT MENU OPTION
SETUP
UPGRADE LANGUAGE DATALOG
M1 M2 M3 M4
SETUP MENU (MORE)
EXIT SYSTEM TANKS
PROBES
M1 M2 M3 M4
M1 M2 M3 M4
To Next Page
