3 of 37
Indesit Company
Service Manual UK English
TECHNICAL SPECIFICATIONS
First Production September 2011
Features Electronically controlled tumble dryer comprising of an interface module
fitted to the rear of the console panel and a control module mounted on
the plinth, connected by a serial link.
Country of Origin Great Britain
Dimensions Height 850 mm
Width 595 mm
Depth 584 mm
Weight 35 Kg (Packed)
Door Reversible ? No
Energy Class Class B or Class C
Noise Level 72 dBA approximately
Drum Volume 112 litres
Drying Load Cottons - 7 Kg, 7.5 Kg, 8 Kg, 9 Kg - depending on model - refer to matrix
Synthetics - 3 Kg
Heater 2300Watts @ 230V or 2050 Watts
Heater Controls Variable using electronic control and thermistors
Sensing Levels Up to 7 levels depending on model - refer to matrix
Thermistor 614 K Ohms @ 20°C
Safety Thermostats
Cycling Thermostat 106°C
One Shot Thermostat 143°C (White Spot)
Motor Type 362 / 363 Single phase, capacitor run, 2 pole induction motor
Capacitor 8.5 uF
Recommended Minimum
Ambient Temperature +5°C
MODEL NUMBER MATRIX
Example Model = TCD93B6PIT
Product Type Display Capacity Dryness
Level
Energy Door Type Colour Market
TCD93B 6 P IT
Tumble
Dryer
C = Condenser
V = Vented
D = LCD
L = LCD
G = Big
Digit
7 = 7 Kg
8 = 8 Kg
9 = 9 Kg
0 - 7
3 = 3 levels
A
B
C
3 = A-
30%
4 = A-
40%
5 = A-
50%
6 = A-
60%
6 = Glass Door
Blank = Solid Door
C = White +
Chrome Door
G = Graphite
H = White +
Anthracite Door
K = Black
P = White
EU = Europe.
EX = Other
IT = Italy.
FR = France.
SK =
Scandinavia
UK =
United
Kingdom.
