Indmar Marine Engines
6-17
TRANSMISSION MODEL RATIO CAPACITY FLUID TYPE
ZF Hurth In-Line ZF 45 D 1:1 1.7 qt (1.6L) Pennzoil Dexron II, III or MERCON
ZF Hurth In-Line ZF 45 A Various 2.12 qt (2L) Pennzoil 15W40
ZF Hurth In-Line ZF 63 A 1.5:1 4.2 qt (4L) Pennzoil 15W40
ZF Hurth V-Drive ZF 63 IV -- 4.2 qt (4L) Pennzoil 15W40
ZF Hurth Ski-Vee ZF 45 IV 1:1.462
2.12 qt (2L) Main Gearbox Pennzoil Dexron II, III or MERCON
1.0 qt (1.06L) V-Drive Unit Pennzoil Dexron II, III or MERCON
Walters V-Drive RV-26D-71V -- 0.5 qt (0.5L) Pennzoil SAE 30 Motor Oil
Do not overfill the transmission. Overfilling
can damage the transmission. Damage to
your transmission due to too much or too
little fluid is not covered by your warranty.
ELECTRICAL SYSTEM
All Indmar engines are equipped with a 35 A circuit
breaker (1, Figure 6-14) to protect the engine electrical
system and components from overload. If the engine will
not crank with the battery switch in the ON position,
locate the red breaker reset button at the back of the
engine. Firmly push the red button until the breaker
resets (an audible click will be heard). Start the engine.
Figure 6.14 – Breaker Reset Button
INDM-A029
1
2
OME0502-07 Body.qxd 6/14/06 10:38 AM Page 6-17
