ASSEMBLY INSTRUCTIONS
Step 4
Attach the reflector dome (1) to the assembled
reflector assembly with six M4 x 10 bolt assemblies (EE).
by a competent person. Proper assembly is
the responsibility of the installer.
Step 3
Attach the assembled reflector assembly to three
mesh support rods (4) with three M4 x 10 bolt assemblies
(EE).
Warning: This appliance requires installation
EE M4 x 10 bolt assembly 3
Hardware used
EE M4 x 10 bolt assembly 6
Hardware used
EE
2
4
EE
1
Step 3:
Step 4:
To Next Page
