ASSEMBLY INSTRUCTIONS
competent person. Proper assembly is the
responsibility of the installer.
Step 5
Warning: This appliance requires installation by a
Attach the spiral (7) to the base assembly (9) with
two M4 x 10 screws (DD).
Attach the glass fixing base (8) to the base assembly (9)
with four M5 x 10 screws (CC).
CC M5 x 10 screw 4
DD M4 x 10 screw 2
Hardware used
7
8
CC
9
9
DD
