Inficon PEG100 - Page 7

tina14e1-a (2017-12) PEG100.om 7
Fig. 1 Dimensional drawing
Weight 500 g approx
Storage temperature range –20 °C to +70 °C
Climatic rating KWF to DIN 40040
Operating temperature range 10 °C to 50 °C
Max. rel. humidity of the ambient air (on 30
days per year, non-condensing) 70 %
1)
or 95 %
2)
1)
usable measurement range 10
-2
to 10
-9
mbar
2)
usable measurement range 10
-2
to 10
-7
mbar
Dimensions [mm], Weight
Ambient Conditions
