Quick Start Guide
Step 1
Connect the EFINIX Ti180 kit adapter
board to the SONY IMX715 image sensor
board.
Page 2 of 2
Date: 10 / 2023
All rights reserved. © 2023
Infineon Technologies AG
Document number: 002-38873 Rev. **
For additional details, see the kit guide available on the Infineon kit webpage.
Before you start
Ensure that you have a PC with USB-C port that
supports 5Gbps or 10Gbps data transfer.
Step 1: Connect and power up the board
Connect the image sensor board with the adapter
board from EFINIX Ti180 kit using the 22-pin FFC
cable.
Step 2
Connect the sensor board to the
Ti180 FPGA kit
Step 2: Connection with Ti180 FPGA kit
Connect the sensor board to the EFINIX Ti180 FPGA
kit.
Step 3
Connect to the FX10 DVK FMC
interface board to FX10 DVK via Ti180
FPGA board
Step 3: Final setup
Connect the Ti180 FPGA board to FX10 DVK FMC
interface.
For additional details on how to stream video from
the SONY IMX715 image sensor board, contact
https://mycases.infineon.com for the FX10-based
camera kit user guide.
