User Manual 5-3 V2.0
Application Kit TC3X7 ADAS V2.0 2018-06
Application Kit Manual TC3X7 ADAS
Hardware: Application Kit TC3X7 ADAS V2.0
Signal (on board used) Description
P11.9 Ethernet RXD1 Input A
P11.10 Ethernet RXD0 Input A
P11.11 Ethernet RCTL Input A
P11.12 Ethernet RXCLK Input A
P12.0 Ethernet Management Data Clock Output (MDC)
P12.1 Ethernet Management Data Input/Output (MDIO)
P10.8 Ethernet MD Interrupt Input
P02.1 Ethernet MD Interrupt Input (optional)
P14.2 QSPI2 Slave Select Output 1 for /SCS of TLF3068x
P15.3 QSPI2 Master Clock Output for SCL of TLF3068x
P15.6 QSPI2 Master Transmit Output for SDI of TLF3068x
P15.7 QSPI2 Master Receive Input B for SDO from TLF3068x
P14.3 Output for Watchdog Input of TLF3068x
P33.8 SMU_FSP0 Output for Error Signal Input of TLF3068x
P33.9 Input for Safe State Signal from TLF3068x (not available with TLF30682QVS01)
P20.6 QSPI0 Slave Select Output 8 for /CS of Display
P20.3 QSPI0 Slave Select Output 9 for /CS of Touch
P20.13 QSPI0 Master Clock Output for SCLK of Display and Touch
P20.14 QSPI0 Master Transmit Output for SDI of Display and Touch
P20.12 QSPI0 Master Receive Input A for SDO from Display and Touch
P20.9 Interrupt Input from Touch /PENIRQ
P15.0 PWM or static Output for Display Backlights
P10.5 QSPI1 Slave Select Output 9 for /CS of SD card
P10.2 QSPI1 Master Clock Output for SCLK of SD card
P10.3 QSPI1 Master Transmit Output for SDI of SD card
P10.1 QSPI1 Master Receive Input A for SDO from SD card
P10.7 Interrupt Input from Card Detect Signal
P02.0 Interrupt Input from Card Detect Signal (optional)
P33[1...4] On board LED’s
P33.0 PWM Signal for Acoustic beeper
P23.1 QSPI4 Slave Select Output 6 for CS of MPC79511 (optional)
P22.3 QSPI4 Master Clock Output for SCK of MPC79511 (optional)
P22.0 QSPI4 Master Transmit Output for SI of MPC79511 (optional)
P22.1 QSPI4 Master Receive Input B for SO from MPC79511 (optional)
P15.1 SDMMC0 Clock Output for SD card
P15.3 SDMMC0 Command Output for SD card
P20.7 SDMMC0 Data 0 Input/Output for SD card
P20.8 SDMMC0 Data 1 Input/Output for SD card
Table 5-6 Peripheral Signals (continued)
Short name Description
