User Manual 5-4 V2.0
Application Kit TC3X7 ADAS V2.0 2018-06
Application Kit Manual TC3X7 ADAS
Hardware: Application Kit TC3X7 ADAS V2.0
Signal (on board used) Description
P20.10 SDMMC0 Data 2 Input/Output for SD card
P20.11 SDMMC0 Data 3 Input/Output for SD card
P50.0 / D1_N RIF0 LVDS negative RX Input Data Channel 0
P50.1 / D1_P RIF0 LVDS positive RX Input Data Channel 0
P50.2 / D2_N RIF0 LVDS negative RX Input Data Channel 1
P50.3 / D2_P RIF0 LVDS positive RX Input Data Channel 1
P50.4 / CLK_N RIF0 LVDS negative RX Input Serial Clock
P50.5 / CLK_P RIF0 LVDS positive RX Input Serial Clock
P50.6 / FR_P RIF0 LVDS positive RX Input Frame Clock
P50.7 / FR_N RIF0 LVDS negative RX Input Frame Clock
P50.8 / D3_P RIF0 LVDS positive RX Input Data Channel 2
P50.9 / D3_N RIF0 LVDS negative RX Input Data Channel 2
P50.10 / D4_P RIF0 LVDS positive RX Input Data Channel 3
P50.11 / D4_N RIF0 LVDS negative RX Input Data Channel 3
/ESR0 MMIC Reset Signal
P21.2 MMIC OK Signal
P02.0 MMIC Input/Output Signal 1
P00.3 MMIC Input/Output Signal 2
P00.4 MMIC Input/Output Signal 3
P00.6 MMIC Input/Output Signal 4
P00.7 MMIC Input/Output Signal 5
P00.8 MMIC Input/Output Signal 6
P00.9 MMIC Input/Output Signal 7
P02.2 MMIC Input/Output Signal 8
P02.8 QSPI3 Slave Select Output 5 for SPI_CS0 of MMIC
P00.2 QSPI3 Slave Select Output 4 for SPI_CS1 of MMIC
P00.5 QSPI3 Slave Select Output 3 for SPI_CS2 of MMIC
P02.5 QSPI3 Master Receive Input A for SPI_SO from MMIC
P02.6 QSPI3 Master Transmit Output for SPI_SI of MMIC
P02.7 QSPI3 Master Clock Output for SPI_SCLK of MMIC
Table 5-6 Peripheral Signals (continued)
Short name Description
