Infiniton VIT2FBN - Before Locating the Fixing Brackets

21
Before locating the fixing brackets
The unit should be placed on a stable, smooth surface (use the packaging). Do not
apply force onto the controls protruding from the hob.
Fix the hob on the work surface by screw four brackets on the bottom of hob (see
picture) after installation.
A(mm)
B(mm)
C(mm)
D
E
760
50 mini
40 mini
Air intake
Air exit 10 mm
A
B
C
D
screw
bracket
Screw hole
base
