Infinity 1211a Service Manual

DIO-00-00108 DIODE FAST RECOVERY FR154 D71,72,73,81,82,83 6
DIO-00-00003 DIODE RECTIFIER 1N4004 D1,260 2
DIO-00-00019 DIODE ZENER 1W,12V 1N4742 D401 1
DIO-00-00006 DIODE SWITCHING SIGNAL 1SS133 / 1N4148 D169,402,403,404,405,406,407,408,411,412 10
TRS-00-00087 TRANSISTOR SMALL SIGNAL PNP "TO-92L" KTA1023Y Q402,403 2
TRS-00-00088 TRANSISTOR SMALL SIGNAL NPN "TO-92L" KTC1027Y Q270,271,401 3
TRS-00-00090 TRANSISTOR SMALL SIGNAL PNP "TO-92" KTA1266GR Q262 1
TRS-00-00110 TRANSISTOR SMALL SIGNAL NPN "TO-92" KTC3198GR Q101,260,261,263 4
RES-00-00479RESISTOR METAL FILM 1/5WF 270 OHM R405 1
RES-00-00437RESISTOR METAL FILM 1/5WF 1KF OHM R151,156 2
RES-00-00482RESISTOR METAL FILM 1/5WF 2KF OHM R117 1
RES-00-00523RESISTOR METAL FILM 1/5WF 4.7KF OHM R113 1
RES-00-00575RESISTOR METAL FILM 1/5WF 7.5KF OHM R118 1
RES-00-00589RESISTOR METAL FILM 1/5WF 9.4KF OHM R111,112 2
RES-00-00402RESISTOR METAL FILM 1/5WF 10KF OHM R150,152,155,157 4
RES-00-00419RESISTOR METAL FILM 1/5WF 13KF OHM R404 1
RES-00-00537RESISTOR METAL FILM 1/5WF 47KF OHM R103,104,105,106,107,108,109,110,402,403 10
RES-00-00606RESISTOR CARBON FILM 1/5WJ 100 OHM R51,52,53,54,55,56,61,62,63,64 13
RES-00-00622RESISTOR CARBON FILM 1/5WJ 150 OHM R125 1
RES-00-00712RESISTOR CARBON FILM 1/5WJ 470 OHM R241,264,341 3
RES-00-00723RESISTOR CARBON FILM 1/5WJ 510 OHM R120,122 2
RES-00-00756RESISTOR CARBON FILM 1/5WJ 820 OHM R116 1
RES-00-00633RESISTOR CARBON FILM 1/5WJ 1K OHM R50,57,60,67,153,158 6
RES-00-00598RESISTOR CARBON FILM 1/5WJ 1.5K OHM R133 1
RES-00-00602RESISTOR CARBON FILM 1/5WJ 1.8K OHM R135 1
RES-00-00702RESISTOR CARBON FILM 1/5WJ 4.7K OHM R114,262,414 3
RES-00-00720RESISTOR CARBON FILM 1/5WJ 5.6K OHM R131,132 2
RES-00-00608RESISTOR CARBON FILM 1/5WJ 10K OHM R44,119,123,128,129,130,261,263,406,407 16
R409,410,412,416,418,419
RES-00-00623RESISTOR CARBON FILM 1/5WJ 15K OHM R121,126 2
RES-00-00630RESISTOR CARBON FILM 1/5WJ 18K OHM R415 1
RES-00-00658RESISTOR CARBON FILM 1/5WJ 22K OHM R101,102 2
RES-00-00666RESISTOR CARBON FILM 1/5WJ 27K OHM R417 1
RES-00-00680RESISTOR CARBON FILM 1/5WJ 30K OHM R124 1
RES-00-00730RESISTOR CARBON FILM 1/5WJ 56K OHM R270,271 2
RES-00-00757RESISTOR CARBON FILM 1/5WJ 82K OHM R169 1
RES-00-00604RESISTOR CARBON FILM 1/5WJ 100K OHM R134,138,154,159,230,231,232,233,234,236 22
R237,238,239,330,331,332,333,334,336,337
R338,339
RES-00-00620RESISTOR CARBON FILM 1/5WJ 150K OHM R127 1
RES-00-00654RESISTOR CARBON FILM 1/5WJ 220K OHM R413 1
RES-00-00727RESISTOR CARBON FILM 1/5WJ 560K OHM R408 1
RES-00-00755RESISTOR CARBON FILM 1/5WJ 820K OHM R260 1
RES-00-00635RESISTOR CARBON FILM 1/5WJ 1M OHM R411 1
RES-00-00018RESISTOR METAL FILM 1/2WJ 10 OHM R220,221,222,223,224,226,227,228,229,320 18
R321,322,323,324,325,327,328,329
RES-00-00794RESISTOR METAL FILM 1WJ 10 OHM R73,83 2
IND-00-00025 INDUCTOR LAL02TB1R0K AXIAL TYPE 5% 1uH L1,2 2
CEC-00-00077CAPACITOR CERAMIC DISK 50V "NPO" 10pF C105,106 2
CEC-00-00090CAPACITOR CERAMIC DISK 50V "NPO" 22pF C131,132,133,134,153,154 6
CEC-00-00101CAPACITOR CERAMIC DISK 50V 470pF C109 1
CEC-00-00074CAPACITOR CERAMIC DISK 50V 102pF C7,107,108,111,406,701,900 7
CEC-00-00076CAPACITOR CERAMIC DISK 50V 104pF C41,42,73,83,170,171,172,173,174,175 24
C176,177,178,179,180,181,182,183,211,261
C262,401,403,411
CEC-00-00124CAPACITOR CERAMIC DISK 50V "MLCC" 104pF C55,409,410 3
ELC-00-00153 CAPACITOR ELECTROLYTIC"SMS" 1uF/50V C113,408 2
ELC-00-00160 CAPACITOR ELECTROLYTIC"SMS" 4.7uF/50V C71,81,114,407 4
ELC-00-00125 CAPACITOR ELECTROLYTIC"SMS" 10uF/16V C110,112 2
ELC-00-00127 CAPACITOR ELECTROLYTIC"SMS" 22uF/16V C101,102,103,104,115,121,151,152 8
ELC-00-00130 CAPACITOR ELECTROLYTIC"SMS" 47uF/16V C260 1
ELC-00-00523 CAPACITOR ELECTROLYTIC"SMS" 100uF/16V C75,85,404 3
ELC-00-00150 CAPACITOR ELECTROLYTIC"SMS" 100uF/35V C72,82 2
ELC-00-00132 CAPACITOR ELECTROLYTIC"SMS" 220uF/16V C270 1
Power Amplifier Reference 1210a/1211a
16
Electrical Parts List
