Infinity 1211a Service Manual

MYC-00-00020CAPACITOR MYLAR 5% 100V 102J C90,91,405 3
MYC-00-00019CAPACITOR MYLAR 5% 100V 103J C280,380 2
MYC-00-00091CAPACITOR MYLAR 5% 63V "TL TYPE" 683J C117 1
MYC-00-00157CAPACITOR MYLAR 5% 63V "TL TYPE" 823J C116 1
MYC-00-00083CAPACITOR MYLAR 5% 63V "TL TYPE" 104J C222 1
MYC-00-00156CAPACITOR MYLAR 5% 63V "TL TYPE" 184J C119 1
MYC-00-00066CAPACITOR MYLAR 5% 63V "TL TYPE" 474J C74,84,118 3
MYC-00-00085CAPACITOR MYLAR 5% 63V "TL TYPE" 105J C2,6,43 3
ICO-00-00003 I.C DUAL OPAMP DIP-08 TL072CP U101,102,103,104,105 5
ICO-00-00170 I.C VOLUME IC DIP-16 NJM 13600D U106 1
ICO-00-00095 I.C COMPORATOR IC DIP-08 KIA393P U401 1
ICO-00-00157 I.C VOTAGE REGULATOR +12V 1A KIA7812PI U71 1
ICO-00-00162 I.C VOTAGE REGULATOR -12V 1A KIA7912PI U81 1
FET-00-00001 F.E.T
N-CH POWER FET "TO-220"
IRF3205 Q51,52,53,54,55,56,61,62,63,64 12
Q65,66
FET-00-00046 F.E.T
N-CH POWER FET "TO-220"
IRF640N Q217,218,219,220,317,318,319,320 8
FET-00-00021 F.E.T P-CH POWER MOSFET IRF9640 Q211,212,213,214,215,311,312,313,314,315 10
DIO-00-00152 DIODE FAST RECOVERY YG225D2 D74,75,76,77 4
DIO-00-00177 DIODE FAST RECOVERY 6A60 D2 1
RES-00-01112RESISTOR MOR-S 2WJ 2.2 OHM R253 1
RES-00-00846RESISTOR MOR-S 2WJ 10 OHM R71,81 2
RES-00-00844RESISTOR MOR-S 2WJ 100 OHM R77,78 2
RES-00-00853RESISTOR MOR-S 2WJ 2.2K OHM R250,251,252,254,255,280,380,401 8
RES-00-01099RESISTOR MOR-S 2WJ 3.9K OHM R76,86 2
RES-00-00947RESISTOR SHUNT RESISTOR 5WJ (3P) 0.01 OHM R240,340 2
ELC-00-00167 CAPACITOR ELECTROLYTIC"SMS" 100/63V C402 1
ELC-00-00010 CAPACITOR ELECTROLYTIC"BP" 10/200V C215,216,217,218,221 5
ELC-00-00187 CAPACITOR ELECTROLYTIC"SHL" 2200/50V C208,210,308,310 4
ELC-00-00716 CAPACITOR ELECTROLYTIC"LXZ" 3300/25V C50,51,52,53,54 5
ELC-00-00033 CAPACITOR ELECTROLYTIC"HC" 8200/50V C76,86 2
MYC-00.-0010CAPACITOR MYLAR 10% 100V "BOX TYPE" 105K C92,93,207,219,220,307 6
MYC-00.-0007CAPACITOR MYLAR 10% 100V "BOX TYPE" 225K C78,88,212,213,312,313 6
MYC-00.-0010CAPACITOR MYLAR 10% 250V "BOX TYPE" 225K C223,820 2
COI-00-00086 INDUCTOR DRUM COIL CL-900A L6,7,9 3
COI-00-00073 INDUCTOR DRUM COIL CL-2200 L3 1
COI-00-00112 INDUCTOR DRUM COIL CL-1920 L8 1
GAP-00-050A0GAP PAD CL-1920 (32 X 60 X 5T) L8 1
COR-TF-00392CORE 44 PHI MAG T1,T2 , 44PHI 3T(0.7X22):10T(0.7X5):3T(0.7X1) 2
TER-00-00163
POWER
3P TERMINAL DST 0010-00 TER1 1
TER-00-00034
SPEAKER
4P TERMINAL TM0009-01 TER2 1
HOD-00-00006FUSE HOLDER PCB TYPE JSF-08031 FUSE1,2,3 3
FUS-AT-00008AUTO FUSE AUTO FUSE 40A SET(3)+ACCESSORY(3) 6
JAC-00-00043 RCA JACK GOLD PLATE DJB-554A RCA101 1
JUP-00-00003 JUMPER
BAR JUMP
35m/m JP1,2,3,4,5,6,7,8,9 9
JUP-00-00005 JUMPER
BAR JUMPER
55 m/m JP10,11,12,13,14,15,16 7
JAC-00-00050 MODULAR JACK 4P,BLACK DEK623PCB4-B MOD1 1
REL-00-00008 RELAY DC 30A 12V CT11-D12S REL1 1
THS-00-00013THERMISTOR FTD5-350 50KC TH 1
VOL-00-00335 VOLUME V12L5(9X5)G(PH2D)N15S 15B20Kx2 VR101 1
VOL-00-00336 VOLUME V12L5(9X5)G(PH2D)N15S 15C50Kx2 VR102 1
VOL-00-00352 VOLUME V12L5(9X5) G(PH2D)N 15S B500x2
VR103 1
VOL-00-00353 VOLUME
V12L5(9X5) G(4R)(PH2D)N 15S 15A2Kx2+15A200Kx2
VR104 1
WIR-00-00017 GND WIRE #1007 AWG #22 BLACK , 3.2PHI 100m/m W1 1
WIR-00-00111 GND WIRE #1007 AWG #22 BLACK , 3.2PHI 60m/m W2 1
WIR-00-00018 GND WIRE #1007 AWG #22 BLACK , 3.2PHI 120 m/m W3 1
TUB-00-00008TEFLON TUBE 0.7 PHI 10 m/m TH 2
CON-00-00002WAFER LWL0640-2P CLIP 1
CON-00-00033WAFER LWL0640-3P 1ST POWER,2ST POWER 2
Power Amplifier Reference 1210a/1211a
17
Electrical Parts List cont'd
