Infinity 1211a Service Manual

ICO-00-00021 I.C SMD PWM TL494C U1 1
ICO-00-00094 I.C SMD "FLP-8" KIA393F U2,3 2
TRS-00-00098 TRANSISTOR SMALL SIGNAL PNP,SOT-23 KTA1504GR Q3,4,5 3
TRS-00-00113 TRANSISTOR SMALL SIGNAL NPN,SOT-23 KTC3875GR Q2,6 2
DIO-00-00117 DIODE SWITCHING SIGNAL RLS4148 D3,4,5,6,7,8 6
RES-08-00035RESISTOR SMD "0805"1/10WF 20KF OHM R32 1
RES-08-00048RESISTOR SMD "0805"1/10WF 27KF OHM R33 1
RES-08-00111RESISTOR SMD "0805"1/10WF 68KF OHM R29 1
RES-08-00021RESISTOR SMD "0805"1/10WF 150KF OHM R28 1
RES-08-00193RESISTOR SMD "0805"1/10WJ 4.7 OHM R11 1
RES-08-00163RESISTOR SMD "0805"1/10WJ 220 OHM R30 1
RES-08-00148RESISTOR SMD "0805"1/10WJ 1K OHM R16,38,39,43,46 5
RES-08-00129RESISTOR SMD "0805"1/10WJ 1.8K OHM R2 1
RES-08-00151RESISTOR SMD "0805"1/10WJ 2.2K OHM R9,10 2
RES-08-00156RESISTOR SMD "0805"1/10WJ 2.7K OHM R3 1
RES-08-00191RESISTOR SMD "0805"1/10WJ 4.7K OHM R7,8,17,24,25,27 6
RES-08-00200RESISTOR SMD "0805"1/10WJ 5.1K OHM R6 1
RES-08-00201RESISTOR SMD "0805"1/10WJ 5.6K OHM R18,19 2
RES-08-00132RESISTOR SMD "0805"1/10WJ 10K OHM R34 1
RES-08-00164RESISTOR SMD "0805"1/10WJ 22K OHM R12,14,15,22,26 5
RES-08-00170RESISTOR SMD "0805"1/10WJ 27K OHM R13 1
RES-08-00182RESISTOR SMD "0805"1/10WJ 33K OHM R5 1
RES-08-00130RESISTOR SMD "0805"1/10WJ 100K OHM R20 1
RES-08-00180RESISTOR SMD "0805"1/10WJ 330K OHM R4 1
RES-08-00149RESISTOR SMD "0805"1/10WJ 1M OHM R21,23,31,35 4
RES-12-00189RESISTOR SMD "1206"1/8WJ 4.7 OHM R1 1
CEC-08-00002CAPACITOR CHIP"0805" 50V 5% 102P C8 1
CEC-08-00040CAPACITOR CHIP"0805" 50V 5% 473P C5 1
CEC-08-00004CAPACITOR CHIP"0805" 50V 5% 104P C3,14,18,20,22 5
TRS-00-00087 TRANSISTOR SMALL SIGNAL PNP KTA1023Y Q1 1
TRS-00-00090 TRANSISTOR SMALL SIGNAL PNP KTA1266GR Q7,8,9,10 4
RES-00-00038RESISTOR METAL FILM 1/2WJ 220 OHM R36,37 2
ELC-00-00250 CAPACITOR ELECTROLYTIC"SRE" 4.7uF/50V C4,9,11,17,23 5
ELC-00-00641 CAPACITOR ELECTROLYTIC"SRE" 22uF/16V C15,16 2
ELC-00-00243 CAPACITOR ELECTROLYTIC"SRE" 100uF/16V C10,12 2
MYC-00-00020CAPACITOR MYLAR 5% 100V 102J C13 1
HED-00-00100HEADER PIN PIN HEADER C-TYPE 6P TM2007-C9G-06P HP1 1
HED-00-00228HEADER PIN PIN HEADER C-TYPE 8P TM2007-C9G-08P HP2 1
ICO-00-00005 I.C SMD QUAD OP AMP "SO-14" TL074CD U501 1
ICO-00-00099 I.C 2.5V SHUNT IC , SOT-89 KIA431F U505 1
ICO-00-00054 I.C DIVIDER
F4
U503 1
ICO-00-00546 I.C COMPARATOR "SO-14"
B2
U504 1
TRS-00-00197 TRANSISTOR HIGH CURRENT PNP,SOT-89 KTA1661Y Q503 1
TRS-00-00115 TRANSISTOR HIGH CURRENT NPN,SOT-89 KTC4373Y Q502 1
TRS-00-00113 TRANSISTOR SMALL SIGNAL NPN,SOT-23 KTC3875GR Q501 1
DIO-00-00117 DIODE SWITCHING SIGNAL RLS4148 D501,502,503,504,505 5
RES-08-00005RESISTOR SMD "0805"1/10WF 1.5KF OHM R558 1
RES-08-00077RESISTOR SMD "0805"1/10WF 4.7KF OHM R505,506 2
RES-08-00135RESISTOR SMD "0805"1/10WJ 10 OHM R508 1
RES-08-00165RESISTOR SMD "0805"1/10WJ 22 OHM R528 1
RES-08-00131RESISTOR SMD "0805"1/10WJ 100 OHM R555 1
RES-08-00148RESISTOR SMD "0805"1/10WJ 1K OHM R509,521,529,553,554 5
RES-08-00126RESISTOR SMD "0805"1/10WJ 1.5K OHM R511 1
RES-08-00151RESISTOR SMD "0805"1/10WJ 2.2K OHM R517 1
RES-08-00174RESISTOR SMD "0805"1/10WJ 3.3K OHM R522 1
RES-08-00191RESISTOR SMD "0805"1/10WJ 4.7K OHM R515,516,552 3
RES-08-00132RESISTOR SMD "0805"1/10WJ 10K OHM R507,525,526,551,556,559 6
RES-08-00164RESISTOR SMD "0805"1/10WJ 22K OHM R523 1
RES-08-00187RESISTOR SMD "0805"1/10WJ 39K OHM R503,504 2
Power Amplifier Reference 1210a/1211a
18
Electrical Parts List cont'd
