Infinity 1211a Service Manual

RES-08-00198RESISTOR SMD "0805"1/10WJ 47K OHM R513 1
RES-08-00204RESISTOR SMD "0805"1/10WJ 51K OHM R512 1
RES-08-00221RESISTOR SMD "0805"1/10WJ 75K OHM R514 1
RES-08-00130RESISTOR SMD "0805"1/10WJ 100K OHM R510 1
RES-08-00149RESISTOR SMD "0805"1/10WJ 1M OHM R520,524,527 3
RES-12-00161RESISTOR SMD "1206"1/8WJ 22 OHM R550,557 2
CEC-08-00042CAPACITOR CHIP"0805" 50V 5% 47pF C510,511,517 3
CEC-08-00028CAPACITOR CHIP"0805" 50V 5% 330pF C505,515,516 3
CEC-08-00004CAPACITOR CHIP"0805" 50V 5% 104pF C512,518,520,523,524,526,528,529,530 9
CEC-12-00008CAPACITOR CHIP"1206" 50V 5% 105pF C521 1
ELC-00-00077 CAPACITOR ELECTROLYTIC CHIP "MV" 2.2uF/50V C1,525,531 3
ELC-00-00070 CAPACITOR ELECTROLYTIC CHIP "MV" 4.7uF/25V C513,522,527 3
ELC-00-00356 CAPACITOR ELECTROLYTIC CHIP "MV" 10uF/16V C533 1
ELC-00-00635 CAPACITOR ELECTROLYTIC CHIP "BP" 22uF/16V"NP" C504 1
MYC-00-00019CAPACITOR MYLAR 5% 100V 103J C514 1
IND-00-00020 INDUCTOR AXIAL TYPE 5% 100uH L501 1
REN-00-00001RESONATOR
2.56MHz CSA256MG
X501 1
VOL-00-00238 VOLUME
SEMI X-TYPE (RG06X502)
5K SEMI VR501 1
HED-00-00214HEADER PIN PIN HEADER C-TYPE 3P TM2007-C9G-03P HP2
HED-00-00215HEADER PIN PIN HEADER C-TYPE 7P TM2007-C9G-07P HP3
DIO-00-00041 DIODE ZENER 0.5W,12V 1N5242 D201,202 2(4)
TRS-00-00087 TRANSISTOR SMALL SIGNAL PNP "TO-92L" KTA1023Y Q204,206,208,210 4(8)
TRS-00-00088 TRANSISTOR SMALL SIGNAL NPN "TO-92L" KTC1027Y Q203,205,207,209 4(8)
RES-00-00401RESISTOR METAL FILM 1/5WF 100 OHM R204 1(2)
RES-00-00463RESISTOR METAL FILM 1/5WF 220 OHM R203 1(2)
RES-00-00590RESISTOR METAL FILM 1/5WF 910 OHM R202,206 2(4)
RES-00-00636RESISTOR CARBON FILM 1/5WJ 1 OHM R207,208,211,212 4(8)
RES-00-00685RESISTOR CARBON FILM 1/5WJ 330 OHM R420,421 2(4)
RES-00-00637RESISTOR CARBON FILM 1/5WJ 2.2K OHM R201,205 2(4)
CEC-00-00076CAPACITOR CERAMIC DISK 50V 104pF C201,202,204,205 4(8)
MYC-00-00088CAPACITOR MYLAR 5% 63V "TL TYPE" 224J C203,206 2(4)
RES-00-01033RESISTOR MOR-S 2WJ "3.8x11" 4.7K OHM R209,210,213,214 4(8)
TRS-00-00096 TRANSISTOR SMALL SIGNAL PNP
KSA/KTA1381
Q202 1(2)
TRS-00-00112 TRANSISTOR SMALL SIGNAL NPN
KSC/KTC3503
Q201 1(2)
HED-00-00214HEADER PIN PIN HEADER C-TYPE 3P TM2007-C9G-03P HP1 1(2)
HED-00-00231HEADER PIN PIN HEADER C-TYPE 5P TM2007-C9G-05P HP7 1(2)
ICO-00-00095
I.C COMPARATOR DIP-8P KIA393P U90 1
RES-00-00437
RESISTOR METAL FILM 1/5WF 1K OHM R97
1
RES-00-00402
RESISTOR METAL FILM 1/5WF 10K OHM R95
1
RES-00-00550
RESISTOR METAL FILM 1/5WF 51K OHM R96
1
RES-00-00556
RESISTOR METAL FILM 1/5WF 56K OHM R94
1
RES-00-00573
RESISTOR METAL FILM 1/5WF 68K OHM R93
1
RES-00-00635
RESISTOR CARBON FILM 1/5WJ 1M OHM R98
1
RES-00-00029
RESISTOR METAL FILM 1/2WJ 1K OHM R192,292
2
CEC-00-00005
CAPACITOR CERAMIC TUBULAR 50V 103P C91,92,93
3
CEC-00-00006
CAPACITOR CERAMIC TUBULAR 50V 104P C90
1
DIO-00-00321
LED BLUE 3PHI
MS-L330CBHSK
LED1,2,3 3
CON-00-00139
WAFER
LAL0640-2P
CLIP 1
CON-00-00140
WAFER
LAL0640-3P
1ST POWER,2ND POWER 2
WIR-AS-00220
WIRE ASS'Y BK,RED
CHL0640-2P(300m/m)
CLIP 1
WIR-AS-00218
WIRE ASS'Y BK,RED,GREEN
CHL0640-3P(300m/m)
1ST POWER 1
WIR-AS-00219
WIRE ASS'Y BK,YELLOW,GREEN
CHL0640-3P(300m/m)
2ND POWER 1
Power Amplifier Reference 1210a/1211a
19
Electrical Parts List cont'd
