THS-00-00013 THERMISTOR NTC RESISTOR FTD5-350 TH01 1
ELC-00-00234 CAPACITOR ELECTROLYTIC "SMS" 470/50V (12.5x20m/m) C51,61 2
ELC-00-00727 CAPACITOR ELECTROLYTIC "WL" 2200/25V (16x25m/m) C04,05,06 3
ELC-00-00714 CAPACITOR ELECTROLYTIC "HC/DL" 4700/50V (25x30m/m) C52,62 2
COR-TF-00405 CORE 44PHI MAGNETICS
T01 , 4(0.7x15):11(0.7x4):8(0.7x1):8(0.7x1)
1
COI-00-00093 INDUCTOR DRUM COIL CL-510 L01,02 2
COI-00-00028 INDUCTOR BAR COIL CL-310 L03 1
SWI-00-00024 SWITCH SLIDE SWITCH JSS-2219 SW102,302 2
JAC-00-00043 RCA JACK GOLD PLATED DJB-554A RCA101 1
JAC-00-00042 RCA JACK GOLD PLATED DJB-562D RCA301 1
TER-00-00030 TERMINAL GOLD PLATED TM0006-01 (3P) TER01 1
TER-00-00021 TERMINAL GOLD PLATED 8P WT-9519 TER02 1
JUP-00-00005 JUMPER METAL JUMPER 55m/m BJ01,02,03,07 4
JUP-00-00003 JUMPER METAL JUMPER 35m/m BJ04,06,09 3
JUP-00-00001 JUMPER METAL JUMPER 20m/m BJ08 1
HOD-00-00011 FUSE HOLDER WF-9604 Fh01 1
CON-00-00002 WAFER LWL0640-2P CLIP 1
CON-00-00033 WAFER LWL0640-3P 1ST POWER,2ND POWER 2
CON-00-00128 WAFER LAD1140-04PBK HI101,301 2
WIR-00-00208 WIRE ASS'Y 300m/m CHD1140-04PBK ACCESSORY 2
WIR-00-00015 WIRE
AWG #22 BK 3.2PHI RING LUG
60m/m W2 1
WIR-00-00018 WIRE
AWG #22 BK 3.2PHI RING LUG
120m/m W1 1
HED-00-00115
HEADER PIN SOCKET
TM2501-DG-14P 14P CON101-1,301-1 2
TUB-00-00008 TEFLON TUBE 0.7PHI 10m/m TH01,Q140,240,340,440 6
FUS-AT-00006 AUTO FUSE 30A SET2+ACCESSORY2 4
ICO-00-00113 I.C DUAL OP AMP "SOP-08" NJM2068M U102,103,104,105,302,303,304,305,306,307
10
RES-08-00239 RESISTOR
SMD 0805 1/10WF 9.31K OHM R257,457
2
RES-08-00022 RESISTOR
SMD 0805 1/10WF 15K OHM R155,255,355,455
4
RES-08-00088 RESISTOR
SMD 0805 1/10WF 47K OHM R256,456
2
RES-08-00117 RESISTOR
SMD 0805 1/10WF 91K OHM R156,356
2
RES-08-00225 RESISTOR
SMD 0805 1/10WJ 820 OHM R108,208,308,408
4
RES-08-00148 RESISTOR
SMD 0805 1/10WJ 1K OHM R391,392,491,492
4
RES-08-00201 RESISTOR
SMD 0805 1/10WJ 5.6K OHM R113,115,213,215,313,315,413,415
8
RES-08-00210 RESISTOR
SMD 0805 1/10WJ 6.8K OHM R396,496
2
RES-08-00132 RESISTOR
SMD 0805 1/10WJ 10K OHM R110,111,112,114,210,211,212,214,310,311
16
R312,314,410,411,412,414
RES-08-00187 RESISTOR
SMD 0805 1/10WJ 39K OHM R393,493
2
RES-08-00141 RESISTOR
SMD 0805 1/10WJ 150K OHM R397,497
2
CEC-08-00023 CAPACITOR
SMD 0805 22pF C156,356
2
CEC-08-00037 CAPACITOR
SMD 0805 39pF C256,456
2
CEC-08-00042 CAPACITOR
SMD 0805 47pF C111,211,311,393,411,493
6
CEC-08-00040 CAPACITOR
SMD 0805 473pF C195,196,295,296,395,396,495,496
8
MYC-00-00157 CAPACITOR MYLAR 5% 63V "TL"
823J C113,115,213,215,313,315,413,415
8
MYC-00-00083 CAPACITOR MYLAR 5% 63V "TL"
104J C391,392,491,492
4
ELC-00-00241
CAPACITOR ELECTROLYTIC"SRE"
10/16V C125,155,225,255,325,355,425,455 8
SWI-00-00033 SWITCH
SLIDE SWITCH JSS2319 SW101,301
2
VOL-00-00349 VOLUME
V9M(7x5) G3(PH2R)N 15S
3B20KBx2 VR101,301,303
3
VOL-00-00351 VOLUME
V9M(7x5) G(4R)(PH2R)N 15S
15C50KCx4 VR102,302
2
HED-00-00249 PIN CONNECTOR
TM2008-D76G-14P 14P CON101,301
2
ICO-00-00095
I.C COMPARATOR DIP-8P KIA393P U90 1
RES-00-00437
RESISTOR METAL FILM 1/5WF 1K OHM R97
1
RES-00-00402
RESISTOR METAL FILM 1/5WF 10K OHM R95
1
RES-00-00550
RESISTOR METAL FILM 1/5WF 51K OHM R96
1
RES-00-00556
RESISTOR METAL FILM 1/5WF 56K OHM R94
1
RES-00-00573
RESISTOR METAL FILM 1/5WF 68K OHM R93
1
RES-00-00635
RESISTOR CARBON FILM 1/5WJ 1M OHM R98
1
RES-00-00029
RESISTOR METAL FILM 1/2WJ 1K OHM R192,292
2
CEC-00-00005
CAPACITOR CERAMIC TUBULAR 50V 103P C91,92,93
3
CEC-00-00006
CAPACITOR CERAMIC TUBULAR 50V 104P C90
1
DIO-00-00321
LED BLUE 3PHI MS-L330CBHSK LED1,2,3 3
CON-00-00139
WAFER LAL0640-2P CLIP 1
CON-00-00140
WAFER LAL0640-3P 1ST POWER,2ND POWER 2
WIR-AS-00220
WIRE ASS'Y BK,RED CHL0640-2P(300m/m) CLIP 1
WIR-AS-00218
WIRE ASS'Y BK,RED,GREEN CHL0640-3P(300m/m) 1ST POWER 1
WIR-AS-00219
WIRE ASS'Y BK,YELLOW,GREEN CHL0640-3P(300m/m) 2ND POWER 1
Electrical Parts List cont'd
Reference 7540a/7541a
To Next Page
