Reference 7541a Electrical Parts List Addendum
The following chart below represents the only electrical parts
differences in 7540a and 7541a models:
MODEL PART NAME PART NUMBER SPEC DESIGNATOR
REF 7540a RESISTOR RES-00-00586 1/5WF 820 OHM R172,272,372,472
1
REF 7541a RESISTOR RES-00-00437 1/5WF 1K OHM R172,272,372,472
REF 7540a RESISTOR RES-00-00417 1/5WF 13.7K OHM R171,271,371,471
2
REF 7541a RESISTOR RES-00-00508 1/5WF 33K OHM R171,271,371,471
REF 7540a RESISTOR RES-08-00225 SMD 0805 1/10WJ 820 OHM R108,208,308,408
3
REF 7541a RESISTOR RES-08-00242 SMD 0805 1/10WF 240 OHM R108,208,308,408
REF 7540a
POWER TERMINAL
TER-00-00030 (3P) TM006-01 TER01
4
REF 7541a
POWER TERMINAL
TER-00-00278 (3P) DK-03B04-AG-5-UP TER01
REF 7540a
SPEAKER TERMINAL
TER-00-00021 (8P) WT-9519 TER02
5
REF 7541a
SPEAKER TERMINAL
TER-00-00274 (8P) DK-0801-AG-5-UP TER02
18
