890 HD BF USERS INSTRUCTIONS
Place a further two log shapes as shown, No 5 shape will need to be located first. Place small pockets of
emberglow in the area highlighted.
Place the four corresponding overlay shapes as shown.
Place the remaing six ember shapes within the inlet cover as shown.
6
5
No 5 log should be located
first
Place a small amount of emberglow in the highlighted below. Excessive amount of the
wire fibre can effect the flame appearance and the cross lighting of the burner
10
9
8
7
