Infinity ALPHA 1200S - Controls and Connections; Rear Panel Controls

2
INFINITY ALPHA 1200S
Rear Panel
CONTROLS AND CONNECTIONS
POWER
AC
120V ~ 60HZ
500W
OFF
ON
®
BASS OPTIMIZATION SYSTEM
20 -14.1 080
FREQUENCY LEVEL
OFF
GREEN: ON
RED: STANDBY
PHASE
LINE LEVEL IN
HIGH
LEVEL
IN
HIGH
LEVEL
OUT
Infinity Systems, Inc.
Northridge, CA USA
R L
+
_
R
L
R
L
180
0
50 150
CROSSOVER
MIN MAX
GAIN
POWER
ON
4.5 49.5
WIDTH
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK,
DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.
AVERTISSEMENT: POUR PRÉVENIR LES RISQUES D'INCENDIE OU
DE CHOC ÉLECTRIQUE, ÉVITER D'EXPOSER CET APPAREIL A LA
PLUIE OU A L'HUMIDITÉ.
NRTL/C
CSA 22.2
UL1492
Alpha 1200s
LP ON
LP OFF













Bass Optimization Controls (see page 5)

Bass Optimization System Selector

Center-Frequency Adjustment

Bass Optimization System Level Adjustment

Bass Optimization System Bandwidth Adjustment

Phase Switch

Low-Pass Filter Selector

Power Indicator

Crossover Adjustment

Subwoofer Gain (Volume) Control

Line-Level Inputs

High-Level (Speaker) Inputs

High-Level (Speaker) Outputs

Power Switch
