Infinity Classia Series User Manual

Parameter Specification Unit
QA Test
Limits
Conditions Notes
Tx-Signal Sensing (ATO)
Auto-Turn-On (yes/no) YES functional
ATO Input test frequency 50 Hz functional
ATO Level LFE Input 2 mV functional
Auto Mute/ Turn-OFF Time 5-15 minutes 5-15
T before muting, after signal is
removed
Auto turn of time (T) must be 5 > T < 15
Minutes
Tx Features --
LFE Input YES -- functional Single RCA Connector
Channel ID switch YES functional
4 Position switch, to select wireless
channels
External power supply
requirements
18 VDC functional
System provided with Power supply model
GPE-152, delivering 18VDC @ 500mA
Power consumption
Tx Power supply
requirements
18 V Reference
Tx Current consumption Amperes Reference
Tx Standby Input Power 1 Watts Reference 120VAC line voltage RED LED
Tx Standby input current 0.019 Amperes Reference 120VAC line voltage RED LED
Tx Idle Power 2.34 Watts Reference 120VAC line voltage
Unit in operation Locked to Rx section
Solid GRN
Tx Idle Power 1.64 Watts Reference 120VAC line voltage Unit in operation NOT locked to Rx section
Other Parameters/Notes:
Volume control should be at the input buffer stage in order to lessen the possibility of clipping the input section with highly dynamic audio material.
ALL SPECS SHOULD BE MEASURED AT NOMINAL LINE VOLTAGE.
4
PSW310W subwoofer Classia Series

Infinity Classia Series Specifications

General

Brand	Infinity
Model	Classia Series
Category	Subwoofer
Language	English
