10
◆
Compositions Overture OVTR 2/OVTR 3 – Owner’s Manual
PERFORMANCE DATA
DRIVE UNITS
AMPLIFIER
(BUILT-IN POWER AMPLIFIER FOR
LOW
-FREQUENCY SECTION)
DIMENSIONS
(also see Figure 7 on page 11)
SPECIFICATIONS – OVTR 3
Frequency Range: 25 ~ 20,000 Hz
Sensitivity: 94 dB @ 2.83 V and 1 m (anechoic conditions)
Impedance: 8 Ω nominal
Maximum Peak Output: 115 dB (spl on program)
Amplifier Requirements: Recommended for use with amplifiers
15 ~ 200 W (@ 8 Ω)
Low Frequency: Four 6
1
⁄2" (165 mm) high-efficiency,
dynamically-balanced, magnetically-
shielded woofers
Mid Frequency: Two 5
1
⁄4" (125 mm) high-efficiency,
magnetically-shielded, mid-range drivers
High Frequency: One 1" (25 mm) soft dome, high-efficiency,
neodymium magnet, magnetically-
shielded tweeter
Crossover Frequencies: 350 and 3,000 Hz
Peak Output: 500 VA
Power Supply: 120 V~ 60 Hz
Power Consumption: 500 W (maximum), 7 W (standby)
Width: 6
7
⁄8" (175 mm); add 3
1
⁄8" (79 mm) for foot bar
Height: 46" (1,168 mm)
Depth: 15
3
⁄4" (400 mm)
Weight: 59 lb or 26.6 kg (each)
