kappa series
Figure 4. Mounting the 62.5i with the grille.
Figure 5. Mounting the 62.5i in a 165mm
speaker location.
Figure 6. Mounting the 62.5i in a standard
speaker location.
Figure 7. Tweeter level adjustment.
INTERMOUNT III MOUNTING RINGS
The Kappa 62.7 and 63.7 speakers are packaged
with two different speaker adaptor rings. The
rings will allow the speakers to be installed into
various factory 6," 6-1/2" and 6-3/4" openings. See
Figure 5. The metal ring can be mounted in many
European vehicles, Japanese vehicles or vehicles
with 6" speaker locations. The plastic ring can be
mounted in many vehicles using 6-3/4" speaker
locations or three-point mounting frames.
UNIPIVOT
™
ROTATING TWEETER
In order to rotate the tweeter on select Kappa
speakers, (1) push the tweeter post inward
and (2) then rotate. Once in position, release
the tweeter to lock in position
(Figure 6). This
feature is only available on the Kappa 52.7, 62.7,
692.7 and 682.7cf speakers.
TWEETER LEVEL ADJUSTMENT
All Kappa series multielement speakers are
equipped with an adjustable tweeter level. On
all two-way speakers, slightly twist the tweeter
faceplate to either the +3dB or 0dB position
(Figure 7). All three-way speakers have a push
button to adjust the tweeter level between the
+3dB and 0dB set
ting
(Figur
e 7)
.
Adjust to
personal preference.
Figure 8. Connecting an in-line crossover to a
62.7i and an amplifier output. Other speaker
models are connected in a similar way.
