Infinity kappa series

K4 SPARE PARTS LIST
Product
Name
SAP name(SKU) SAP Description Location Usage
K4 10703000358 POTENTIOMETER B10K ±10% K4 VR100 VR102 2
K4 10703000359 POTENTIOMETER C100K ±10% K2/K4/K5 VR101 VR103 2
K4 40403000040 BRIDGE F16A20CT 16A 200V K2/K4/K5 D15P 1
K4 40403000041 BRIDGE F16C20CT 16A 200V K2/K4/K5 D14P 1
K2/K4/K5 40703000001 STATIC INHIBITOR 15KV K4
ESD23 ESD23_1 ESD24
X1B X2B X104 X416
7
K2/K4/K5 40903000162 LED WHITE K2/K4/K5
LED2,LED3,LED4,LED5,LE
D8,LED11
6
K2/K4/K5 40903000172 LED RED/WHT 4P K2/K4/K5 LED1 1
K2/K4/K5 50303000014 FET DIP IRF3205 110A 50V K4/K5 M1 M2 M4 M6 4
K2/K4/K5 50303000047 MOSFET SM2307PSAC K2/K4/K5 M1A M1B M1C M1D 4
K2/K4/K5 50403000077 MOSFET FDD390N15A 150V/26A K2/K4/K5
Q3A Q3B Q3C Q3D Q4A
Q4B Q4C Q4D
8
K2/K4/K5 50703000019 PHOTOCOUPLER TLP185 4P K4/K5 U10P,U11P 2
K2/K4/K5 60103000026 IC IRS2092 SOIC16N K2/K4/K5 U1A U1B U1C U1D 4
K2/K4/K5 60103000195 IC APX809-29SA RESET K4/K5 U1M 1
K4 60103000208 IC CW1117-ADJ K4 U4P 1
K4 60103000232 IC 4560 K4
U109，U100 U300
U302，U107 U108 U121
7
K4 60103000363 IC TL074 K4
U9 U103 U106 U111
U116
5
K2/K4/K5 60103000383 IC TL494C K4/K5 U18 1
K2/K4/K5 60103000654 IC NJM4580V SSOP8 K2/K4/K5
U1N U2B U101 U104
U105 U110 U117 U119
U122 U123 U301
11
K2/K4/K5 60103000724 IC MX25L3206EM2I-12G K2/K4/K5 U3M 1
K2/K4/K5 60103000991 IC HP5013A18E 1.8V K2/K4/K5 U6M 1
K2/K4/K5 60103000992 IC HP5013A33E 3.3V K2/K4/K5 U5M U7M U8M 3
K4 60103001416 IC WM8281 BAG138 DSP K2/K4/K5 U1B 1
K4 60103001419 IC 7912 TO-252 1A K2/K4/K5 U3P 1
K4 60103001420 IC 7812 TO-252 1A K2/K4/K5 U1P U2P 2
K4 60103001423 IC WT51F108-MG10BWT K2/K4/K5 U8P 1
K4 60103001455 IC TPS7095 5V/150mA 2.7-30V K2/K4/K5 U12P 1
K4 60103101422 IC STM8AF5288TC W/S.W. K2/K4/K5 U2M 1
K4/K5 80523000012 THERMISTOR 20K ±5% K4/K5 NTC2 1
K2-K4 90503000047 BT MODULE BM153-32 K2-K4 U1H 1
K4/K5 110103000061 SLIDE SWITCH 8P3T K4/K5 SW1 1
K4/K5 110103000062 SLIDE SWITCH 14*6.5*8.5H 2P3T K2/K4/K5 SW3 SW4 2
K4/K5 110203000016 ROTATY SWITCH 360° K2/K4/K5 S1 1
K4/K5 110403000028 TACT SWITCH 2PIN 250gf K2/K4/K5 K1,K2,K3,K4,K6,K5 6
K4/K5 120203000085 RCA JACK K4/K5 J1 1
K4/K5 121103000003 NETWORK JACK 8PIN K2/K4/K5 J22 1
K4/K5 121103000297 USB JACK 5PIN 0.65MM K2/K4/K5 J1B 1
K4/K5 140203000050 FUSE 30A 32V UL K2/K4/K5 F1-1 F1-2 2
K2-K4 150203000008 BT ANTENNA L180MM K2-K4 1
K4/K5 160203000133 X'TAL OSCILLATOR 12.288MHz 3.3V K4/K5 X1 1
K4/K5 170103001071 CABLE 12PIN L=6M K4/K5 J1A 1
K4 200403000207 TRANSFORMER K4 T1 1
K4 ZS0201000071 DECORATIVE SHEET 211.3*92*12.4 K4 1 1
K4 XG0201100209 BOTTOM PLATE K4 5 1
K4 MK0201200455 FUSE COVE 2P K4 6 1
