Infinity PRELUDE MTS Service Manual

Mechanical & Packaging Parts List
1 Cabinet Prelude MTS Subwoofer (Not for Sale)
2 Low Frequency Transducer
(Woofer)
12” Cast frame C.M.M.D., Shielded
DC Resistance 7.6 ohms ±10%
335036-001
3 Complete Subwoofer Amp assembly Not For Sale
4 Woofer Grille retainers (4) 66815-01
5 Woofer gasket 335481-001
6 Woofer Grille 335037-001
7 Cosmetic Cap Logo 335351-001
8 Woofer Trim Ring 335040-001
9 Front Foot 335038-001
10 Rear Foot 335244-001
11 Terminal Connector Plate 335379-001
12 Cosmetic Cap 335256-001
13 Cosmetic Cap Gasket 335360-001
14 Cosmetic Cap Grille retainers (3) 333249-001
15 Binding Post, BLK, Tower Conn. 335358-001
16 Binding Post, RED, Tower Conn. 335358-002
17 Binding Post, BLK, Rear Panel JC0151
18 Binding Post, RED, Rear panel JC0150
19 Subwoofer Outer Carton 335059-001
20 Subwoofer Top End Pad 335058-001
21 Subwoofer Bottom End Pad 335058-002
22 System Owner’s manual 335060-005
23 Warranty Card
335841-001
24 Survey Card
335868-002
25 Power Cord
WI0043
26 Double-ended Banana Plug
335357-001
27 Hardware Kit
335849-001
28 Alignment Pins (2)
335348-001
29 Spike foot set
331360-001
30 T-Handle Allen Key
335851-001
31 RABOS Complete kit
335852-001
32 RABOS Test CD
335855-001
33 RABOS Sound Level Meter
335368-001
34 RABOS Key (Screwdriver)
091-00121-000
35 RABOS Q-Finder
335856-001
36 RABOS Pouch
335853-001
9 Volt Battery
Prelude MTS Subwoofer

Infinity PRELUDE MTS Specifications

General

Brand	Infinity
Model	PRELUDE MTS
Category	Speaker System
Language	English
