Infinity Reference 1600A User Manual

Part Number Qty
Reference Designato
r
Description
MECHANICAL
HG-0005-2601 Rear plate
214*70*1.2mm, H1-144 silver painting with
silkscreen
1
MK-0004-2601 Front plate
214*70*1.2mm, H1-144 silver painting with
silkscreen
1
KG-100100500 Snap buttom T07-003-01 φ11*φ14*10.8 Black ABS 4
LS1AA0200501 Screw PA2*5 Black zinc 1
LS1FM0300011 Screw KM 3*6MM Black zinc 5
CP-B00011400 Lens 40*10.8*5.7mm PC plastic cold grey10C 1
GD-600011400 Reflector board 270*53.5*13mm clear blue PC plastic 1
SG-0016-2601 Top plate
360*227*62mm dia- casting aluminum alloy, H1
-
144 silver painting with silkscreen
1
SR-1600-0117 Heatsink 325*216*59mm Alum. Hair with painting 1
BA-20001-000 wire harness Φ3*100MM White 1
DQ8069032084 Washer Φ6.9*Φ3.2*0.8MM 3
JD-A01970515 Round mat Φ5.0*2.0 Black EVA One side with glue 6
1600a Reference Series
22
