Infinity Reference 1600A User Manual

REFERENCE 1600a Electrical Parts List
Part Number Qty
Reference Designato
r
MAIN BOARD
Resistors
0702-0106-03 Resistor
10mΩ ±1% manganin resistor 1.5 0.5MM
16.5MM
3 R127 R126 R124
0701-2000-02 Resistor SMD 0Ω 1/8W ±5% 0805 2
R52 R51
0702-4103-02 Carbon resistor 1W 10KΩ ±5% TR 15MM 1
R69
0701-2100-02 Resistor SMD 10Ω 1/8W ±5% 0805 6
R111 R112 R110 R109 R108 R10
7
0701-2101-02 Resistor SMD 100Ω 1/8W ±5% 0805 23
R165 R164 R163 R162 R161 R160 R159
R144 R128 R125 R101 R90 R89 R86 R74
R47
0701-2221-02 Resistor SMD 220Ω ±1/8W 5% 0805 3
R60 R170 R6
5
0701-2102-02 Resistor SMD 1KΩ 1/8W ±5% 0805 7
R18 R151 R152 R91 R54 R53 R1
0
0701-2202-02 Resistor SMD R0805 2KΩ 1/8W ±5% TR 1
R146
0701-2222-02 Resistor SMD 2.2KΩ 1/8W ±5% 0805 7
R197 R185 R140 R135 R134 R157 R15
8
0701-2472-02 Resistor SMD 4.7KΩ 1/8W ±5% 0805 3
R32 R39 R87
0701-2512-02 Resistor SMD 5.1KΩ 1/8W ±5% 0805 4
R38 R200 R82 R81
0701-2562-02 Resistor SMD 5.6KΩ 1/8W ±5% 0805 2
R147 R85
0701-2103-02 Resistor SMD 10KΩ 1/8W ±5% 0805 9
R76
0701-2153-02 Resistor SMD 15KΩ 1/8W ±5% 0805 1
R70
0701-2203-02 Resistor SMD R0805 20KΩ 1/8W ±5% TR 5
R1 R8 R17 R184 R10
4
0701-2223-02 Resistor SMD 22KΩ 1/8W ±5% 0805 2
R5 R4
0701-2333-02 Resistor SMD 33KΩ 1/8W ±5% 0805 1
R98
0701-2473-02 Resistor SMD 47KΩ 1/8W ±5% 0805 22
R181 R180 R97 R92 R26 R25 R14 R23 R15
R11 R9 R13 R77 R68 R6 R7 R75 R24 R195
R194 R196 R71
0701-2563-02 Resistor SMD 56KΩ 1/8W ±5% 0805 1
R95
0701-2104-02 Resistor SMD 100KΩ 1/8W ±5% 0805 5
R63 R62 R84 R83 R96
0701-2154-02 Resistor SMD 150KΩ 1/8W ±5% 0805 2
R94 R93
0702-3220-02 Carbon resistor 1/2W 22Ω ±5% TR 12.5MM 3
R169 R168 R16
7
0702-4682-02 Carbon resistor 1W 6.8K ±5% 15mm 2
R176 R177
0702-4123-02 Carbon resistor 1W 12K ±5% 15mm 1
R120
0712-64R7-02 Metalfilm resistor 2W 4.7Ω ±5% 10MM 1
R139
0702-6221-02 Carbon resistor 2W 220Ω ±5% TR 17.5MM 1
R136
0705-5470-02 Resistor 5W 47Ω ±5% 1
R142
0701-2204-02 Resistor SMD 200KΩ 1/8W ±5% 0805 1
R61
0701-2753-02 Resistor SMD 75K ±5% 1/8W 0805 1
R103
0702-3331-02 Carbon resistor 1/2W 330Ω ±5% TR 12.5MM 2
R66 R67
0701-2392-02 Resistor SMD 3.9KΩ 1/8W ±5% 0805 1
R80
0702-34R7-02 Carbon resistor 1/2W 4.7Ω ±5% TR 12.5MM 1
R119
06D1C106C001 Metalfilm resistor 10UF/250V ±10% 13.5*24 25.5mm 4
C141 C67 C106 C101
0703-3222-03 Metalfilm resistor 1/2W 2.2KΩ ±1% TR 1
R131
0702-5222-02 Cement Resistor 5W 2.2K ±5% =25mm 1
R130
0701-2242-02 Resistor SMD 2.4KΩ 1/8W ±5% 0805 1
R37
0701-2272-02 Resistor SMD 2.7KΩ 1/8W ±5% 0805 1
R27
0701-2471-02 Resistor SMD 470Ω 1/8W ±5% 0805 1
R50
0701-1753-02 Resistor SMD 75KΩ 1/10W ±5% 0603 2
R172 R173
1204-5041-05 Potentiometer
9MM R0971G C500K KQL=15MM T=7.5MM
M=1MM ±10% BASS BOOST
1 VR4
1204-5031-30 Potentiometer B50K ±10% KQ LP FREQ. 1 VR2
1201-2031-02 Potentiometer A20K KQ L=15mm LEVEL 1 VR1
Capacitors
06S121046000 Capacitor SMD 0.1uF/50V 0805 X7R ±10% 23
C138 C137 C121 C120 C118 C115 C108
C90 C89 C76 C51 C48 C34 C29 C28 C27
C26 C21 C20 C19 C18 C116 C128
06S124716000 Capacitor SMD 470pF/50V 0805 X7R ±10% 3
C150 C149 C3
0
06S321026000 Capacitor SMD 1000pF/50V 0805 NPO ±5% 1
C44
06S321016000 Capacitor SMD 100pF/50V 0805 NPO ±5% 8
C17 C40 C22 C16 C36 C37 C15 C3
8
