Infinity Reference 1600A User Manual

Part Number Qty
Reference Designato
r
Description
MAIN BOARD
06S322206000 Capacitor SMD 22pF/50V 0805 NPO ±5% 3
C45 C33 C32
06S321006000 Capacitor SMD 10pF/50V 0805 NPO ±5% 3
C12 C13 C14
06D342227400 MET capacitor (BOX)222/100V ±5% Yellow TR 5
C25 CX1 C97 C23 C2
4
06D374717400 Tan capacitor 470pF/100V ±5% 5.5mm TR 1
C124
06D241546000 MET capacitor 0.15UF/50V ±20% TR 5mm 1
C46
06D324747700 metallized Capacitor 474J/100V 5*11MM ±5% Brown TR 5MM 2
C135 C152
06D1C4747701 Metalfilm resistor 474/100V ±10% Brown TR 7.5mm 2
C98 C99
06D321047200 Terylene capacitor 104/100V ±5% Green TR 5MM 7
C122 C65 C119 C85 C86 C139 C14
0
06D341537400 MET capacitor 153/100V ±5% 5MM TR 1
C53
06D22102C000 MET capacitor 102/250V TR 5mm ±20% 1
C144
06D342247400 MET capacitor 224/100V ±5% TR 5MM 2
C103 C102
06D341839400 MET capacitor 183/63V ±5% Yellow 5MM 1
C52
06D343339400 MET capacitor 333/63V ±5% TR 5MM 1
C47
06D341039000 MET capacitor 103/63V ±5% TR 5mm 3
C54 C125 C12
6
06D2C3357700 Metalfilm resistor 3.3UF/100V ±20% 105℃Brown 20.5mm 1
C105
06D2C335C700 Metalfilm resistor 3.3UF/250V ±20% 105℃Brown 27mm 1
C96
06D212264102 E-capacitor 22uF/25V ±20% 5*11 105℃ Black 5MM TR 1
C136
06D211074100 E-capacitor 100uF/25V ±20% 6.3*11 105℃ Black 5MM TR 4
C129 C131 C130 C4
2
06D212264103 E-capacitor 220uF/25V ±20% 8*12 105℃ Black 5MM TR 2
C88 C87
06D214764102 E-capacitor 47uF/25V ±20% 5*11 105℃ Black 5MM TR 3
C50 C49 C3
5
06D214775101 E-capacitor 470UF/35V ±20% Ф8*20MM 105℃ Black 3
C134 C133 C12
7
06D212285101 E-capacitor 2200UF/35V Φ16*26MM ±20% 105℃ 7.5MM 4
C112 C111 C110 C10
9
06S121244000 Capacitor SMD 0.12UF/25V 0805 X7R ±10% 1
C123
06D212256301 E-capacitor 2.2UF/50V ±20% 5*11 105℃ Orange 5mm TR 1
C41
06D21478H001 E-capacitor 4700UF/80V ±20% 105℃ 35*30mm 10.5mm 4
C145 C146 C147 C14
8
06D212266010 E-capacitor 22uF/50V ±20% 5*11 105℃ TR 5.0MM 6
C3 C4 C7 C8 C10 C31
06D214766001 E-capacitor 47uF/50V ±20% 6.3*11 105℃ TR 5MM 1
C39
Semiconductors
04GS-R104-00 High speed diode FR104 1A 400V 52MM TR 10 D29 D28 D27 D26 D25 D24 D23 D22 D21
04ZL-4004-03 Diode IN4004 DO-41 TR 1
D16
04WY-51AV101 Zener diode SMD 5.1V DO-213AA 0.5W 2
DZ3 DZ2
04PT-4148-01 Diode SMD 1N4148 DO-213AA 16
D43 D51 D44 D46 D45 D48 D47 D6 D1 D14
D13 D12 D11 D10 D9 D42
04ZL-2512-00 Diode SMD MUR120 1A 2512 2
D35 D34
04ZL-6A10-00 Diode 6A10 1000V 1
D17
03T1-Z48N-02 MOS FET IRFZ48N TO-220 8
Q28 Q27 Q26 Q25 Q24 Q23 Q22 Q21
03N1-5551-04 Transistor SMD MMBT5551LT1 NPN SOT-23 14
Q38 Q40 Q1 Q4 Q39 Q37 Q36 Q8 Q7 Q6
Q5 Q2 Q3 Q34
03N1-2222-04 Transistor SMD BT2222 NPN SOT-23 1
Q29
03D1-38N2-02 MOS FET IRFB 38N20D TO-220 6
Q14 Q13 Q12 Q11 Q10 Q
9
01FA-7912-04 Regulator KA7912 TO-220 FAIRCHILD 1
U14
01JR-4560-08 IC DIP NJM4560D Dual Op-amp DIP-8 6
U6 U5 U4 U3 U2 U1
2601-0202-00 Optocoupler LCR-0202 1
LCR1
2202-1620-05 Rectifier MUR1620CTA KAD 16A/200V TO-220 2
D33 D32
2202-1602-05 Rectifier UF1602CT AKA 16/200V TO-220 2
D31 D30
01FA-7812-04 Regulator KA7812E TO-220 FAIRCHILD 2
U13 U15
Miscellaneous
1400-0001-16 RJ45 Jack 16PIN RJ45 2*10P16C 1
RJ1
3000-INIT-03 HF transformer
φ47 4:19:8:6 L1=L2=φ1.0*8*4TS
S1=S2=φ0.8*6*19TS S3=S4=φ1.0*1*8TS
S5=S6=φ1.0*1*6TS
1L8
1380-0209-00 Temperature switch 80℃±5℃ TO-220 PIN 2PCS 1
SW2
1500-0400-01 Terminal Golden crosshead screw 1
1500-0300-01 Terminal Golden crosshead screw 1
2901-224C-00 Relay DC12V 30A 1
RL1
1004-3000-10 HF bead 30UH φ12 φ5 11.5mm 2
L12 L11
1502-0504-00 Jack Pitch 2.0MM 5PIN Bend 90degree 1
CN1
1600a Reference Series
19
