Infinity Reference 1600A User Manual

Part Number Qty
Reference Designato
r
Description
MAIN BOARD
1001-1015-10 Common mode choke 5MU 60A φ47 22mm*18mm 1
L6
1001-4000-10 Inductor 40UH 40A core:ETD-49 φ0.1*80*14TS 1
L4
1001-3001-10 HF inductor 35UH φ25 φ0.3*20*2 1
L4
1413-0001-00 Phone Jack 6P4C RJ11 Black 1
JK1
1404-0004-00 RCA Jack 4 Jacks white red golden 1
J1
1401-0001-03 Fuse holder 3PIN 1
for F1
1601-253G-00 Fuse 25A/32V 6
F1
POWER BOARD
0701-2104-02 Resistor SMD 100KΩ 1/8W ±5% 0805 1
R154
0701-2113-02 Resistor SMD 11KΩ 1/8W ±5% 0805 1
R171
0701-2153-02 Resistor SMD 15KΩ 1/8W ±5% 0805 1
R175
0701-2222-02 Resistor SMD 2.2KΩ 1/8W ±5% 0805 1
R132
0701-2472-02 Resistor SMD 4.7KΩ 1/8W ±5% 0805 1
R46
0701-2432-02 Resistor SMD 4.3KΩ 1/8W ±5% 0805 1
R102
0701-2103-02 Resistor SMD 10KΩ 1/8W ±5% 0805 3
R149 R36 R3
4
0701-2123-02 Resistor SMD 12KΩ 1/8W ±5% 0805 1
R35
0701-2102-02 Resistor SMD 1KΩ 1/8W ±5% 0805 2
R155 R156
0701-2202-02 Resistor SMD R0805 2KΩ 1/8W ±5% TR 1
R138
0701-2473-02 Resistor SMD 47KΩ 1/8W ±5% 0805 2
R19 R20
0701-2623-02 Resistor SMD 62KΩ 1/8W ±5% 0805 1
R12
06S321046000 E-capacitor SMD 0.1uF/50V 0805 NPO ±5% 1
C1
06S321026000 Capacitor SMD 1000pF/50V 0805 NPO ±5% 1
C143
06S321046000 Capacitor SMD 0.1uF/50V 0805 NPO ±5% 8
C79 C81 C82 C84 C117 C132 C80 C151
1003-1010-08 Inductor SMD 100MH 100MHZ 4A 2
L1 L2
04PT-4148-01 Diode SMD 1N4148 DO-213AA 10
D18
03N1-5551-04 Transistor SMD MMBT5551LT1 NPN SOT-23 1
Q33
03P1-5401-04 Transistor SMD MMBT5401LT1 PNP SOT-23 1
Q32
03P1-1023-01 Transistor DIP 2SA1023 TO-92 PNP TR 2
Q19 Q20
03P1-B649-07 Transistor DIP 2SB649A 1.5A 180V 20W PNP TO-126 1
Q17
01TI-L494-09 IC PWM SMD TL494C SO-16 1
U18
1501-0509-04 Clubfoot pin DIP PITCH 2.54mm 5PIN Bend 90 degree 1
CN7
1501-0409-02 Clubfoot pin DIP PITCH 2.54mm 4PIN Bend 90 degree 1
LED BOARD
2004-0017-00 LED φ3 White with blue light 8
2100-0035-05 FFC 5PIN 2.0 UL1007 28AWG L=100mm 2.0 105℃ 1
2000-0017-00 LED DIP Red with red ligth Φ3MM 2P 1
LED101
2004-0014-00 LED DIP Φ3.0MM Blue with blue light 1
LED100
0701-6102-02 Resistor SMD 1KΩ 1/2W ±5% 2010 2
2102-0153-02 FFC
2PIN UL1007 red black 28AWG L=320mm
5mm
1
2102-0154-02 FFC 2PIN UL1007 red black 28AWG L=40mm 5mm 1
1502-0504-00 Jack DIP Pitch 2.0MM 5PIN Bend 90 degree 1
06S121046000 Capacitor SMD 0.1uF/50V 0805 X7R ±10% 2
C1 C2
04PT-4148-01 Diode SMD 1N4148 DO-213AA 2
D1 D2
SIGNAL BOARD
Resistors
0701-2104-02 Resistor SMD 100KΩ 1/8W ±5% 0805 1
R64
0701-2103-02 Resistor SMD 10KΩ 1/8W ±5% 0805 4
R3 R33 R30 R31
0701-2100-02 Resistor SMD 10Ω 1/8W ±5% 0805 4
R117 R118 R193 R19
8
0701-2102-02 Resistor SMD 1KΩ 1/8W ±5% 0805 2
R55 R58
0701-2222-02 Resistor SMD 2.2KΩ 1/8W ±5% 0805 2
R105 R106
0701-2203-02 Resistor SMD R0805 20KΩ 1/8W ±5% TR 1
R2
0701-2472-02 Resistor SMD 4.7KΩ 1/8W ±5% 0805 5
R40 R41 R42 R43 R4
4
0701-2431-02 Resistor SMD 430Ω ±5% 1/8W 0805 1
R45
1600a Reference Series
20
