Infinity Reference 1600A User Manual

Part Number Qty
Reference Designato
r
Description
SIGNAL BOARD
0701-2681-02 Resistor SMD 680Ω 1/8W ±5% 0805 2
R116 R19
9
0701-2152-02 Resistor SMD 1.5KΩ 1/8W ±5% 0805 1
R56
0701-2101-02 Resistor SMD 100Ω 1/8W ±5% 0805 3
R49 R191 R19
2
0701-2303-03 Resistor SMD 30K 1/8W ±1% 0805 1
R29
0701-2221-02 Resistor SMD 220Ω ±1/8W 5% 0805 1
R113
0701-2331-02 Resistor SMD 330Ω 1/8W ±5% 0805 1
R48
0701-2473-02 Resistor SMD 47KΩ 1/8W ±5% 0805 1
R57
Capacitors
06D211076100 E-capacitor DIP 100uF/50V ±20% 6.3*11 105℃ Blk 5MM 2 C93 C94
06S321026000 Capacitor SMD 1000pF/50V 0805 NPO ±5% 1
C100
06S321016000 Capacitor SMD 100pF/50V 0805 NPO ±5% 2
C61 C62
06S321046000 Capacitor SMD 0.1uF/50V 0805 NPO ±5% 8
C57 C59 C60 C63 C75 C77 C91 C9
2
06S132253000 ceramic capacitor SMD 2.2uF/16V 1206 X7R ±10% 2
C104 E1
06D344727400 MET Capacitor DIP 472/100V ±5% TR 5MM 2
C55 C56
06S123326000 Capacitor SMD 332/50V ±10% X7R 0805 1
C64
06D214764102 E-capacitor DIP 47uF/25V ±20% 5*11 105℃ Black 5MM TR 1
C43
06D211074100 E-capacitor DIP 100uF/25V ±20% 6.3*11 105℃ Blk 5MM 1
C58
Semiconductors
0100-C081-08 IC TLC081 SOP-8 Op-Amp 1
U8
2601-4N35-00 Optocoupler 4N35 DIP6 1
U17
01LM-M555-08 IC SMD LM555 Timer SOP-8 1
U7
0100-74AH-00 IC 74AHC1G04 Inverter SOT-235 1
U16
0100-2010-00 IC IR2010S High/Low side driver SOL-16 1
U10
03P1-5401-04 Transistor SMD MMBT5401LT1 PNP SOT-23 1
Q30
01TC-WH04-00 IC TC7WH04F Triple Inverter 1
U9
04ZL-2512-00 Diode SMD MUR120 1A 2512 1
D8
01LM-M311-08 IC SMD LM311 Comparator SOP-8 1
U11
04PT-4148-01 Diode SMD 1N4148 DO-213AA 5
D2 D3 D4 D7 D4
9
04WY-51AV101 Zener diode SMD 5.1V DO-213AA 0.5W 1
DZ1
Miscellaneous
1505-1009-04 Clubfoot pin DIP PITCH 2.54mm 10PIN Bend 90 degree 2
CN6
MECHANICAL
ZL-A0001A-15 6.5PC Pole φ7.5*φ3.0*6.4mm LASK-5 2
PL-L0007-000 Cliper 30*36*0.8mm 1
PL-L0006-000 Cliper 30*28*0.8mm 10
JY222A18A01X Mica 22*18*0.1MM 1
JY233A22A001 Mica 33*22*0.1mm 1
JY297A22A001 Mica 97*22*0.1mm 1
JY264A22A001 Mica 64*22*0.1mm 1
JY242A22A001 Mica 42*22*0.1mm 1
ZA-H00040100 Snap buttom φ7.5 M3.5*4 4
LS1AM0250401 Screw Plating black zinc 2.5*4 4
JY217A12A10A ceramic plate 17*12*1.0mm white 6
LS1AA0301501 Screw PA3*15 plating black zinc 2
LS1FJ0200801 Screw KA2*8 plating black zinc 2
LS5KJ0301007 Screw 3*10MM Plating nickel 3
LS5KP0300807 Screw 3*8MM Plating nickel 8
LS1AP0300607 Screw 3*6MM Plating nickel 6
LS1AM0300607 Screw PM3*6 Plating nickel 2
KT-200012200 CAP White PVC for RCA 2
KT-200021300 CAP Red PVC for RCA 2
LS1AY0301201 Screw PM3*12MM plating zinc 4
XG-0017-2601 Bottom plate 325*182*1.2mm, H1-144 silver painting 1
