Infinity Reference 310a Service Manual

PART NO NOMENCATURE DESCRIPTION MFR PARTS REF NO Q'TY
ELC-00-00198 CAPACITOR ELECTROLYTIC "SMS" 47/16V C11,14 2
ELC-00-00205 CAPACITOR ELECTROLYTIC "SMS" 47/25V C16 1
ELC-00-00227 CAPACITOR ELECTROLYTIC "SMS" 47/50V C57,67 2
ELC-00-00199 CAPACITOR ELECTROLYTIC "SMS" 100/16V C12,13,17,171,181,271 6
ELC-00-00200 CAPACITOR ELECTROLYTIC "SMS" 220/16V C191,291 2
ELC-00-00201 CAPACITOR ELECTROLYTIC "SMS" 330/16V C192,292 2
MYC-00-00020 CAPACITOR MYLAR 5% 100V 102(M) J C21 1
MYC-00-00031 CAPACITOR MYLAR 5% 100V 222(M) J C08 1
MYC-00-00038 CAPACITOR MYLAR 5% 100V 473(M) J C140,240 2
MYC-00-00045 CAPACITOR MYLAR 5% 100V 823(M) J C113,115,213,215 4
MYC-00-00094 CAPACITOR MYLAR 5% 100V 104(M) J C161,198,199,261,298,299 6
MYC-00-00085 CAPACITOR MYLAR 5% 63V "TL" 105(M) J C01,31,32 3
CEC-00-00077 CAPACITOR CERAMIC DISK 50V "NPO" 10P F C104,204 2
CEC-00-00084 CAPACITOR CERAMIC DISK 50V "NPO" 18P F C156 1
CEC-00-00090 CAPACITOR CERAMIC DISK 50V "NPO" 22P F C105,106,126,205,206,226 6
CEC-00-00097 CAPACITOR CERAMIC DISK 50V "NPO" 33P F C256 1
CEC-00-00103 CAPACITOR CERAMIC DISK 50V "NPO" 47P F C111,197,211,297 4
CEC-00-00108 CAPACITOR CERAMIC DISK 50V "NPO" 68P F C121,221 2
CEC-00-00073 CAPACITOR CERAMIC DISK 50V "NPO" 100P F C132,142,151,232,242,251 6
CEC-00-00074 CAPACITOR CERAMIC DISK 50V 102P F C101,201 2
CEC-00-00102 CAPACITOR CERAMIC DISK 50V 473P F C33,53,63,200,400,801 6
CEC-00-00076 CAPACITOR CERAMIC DISK 50V 104P F C03,22,60 3
JUP-00-00043 JUMPER 0OHM JUMPER 6m/m J15,16,17,18,73,74,95,96,98,99 29
J100,119,121,124,125,129,130,132,135,136
J138,141,180,181,310,311,312,314,341
JUP-00-00044 JUMPER 0OHM JUMPER 7.5m/m J01,02,03,04,10,11,12,13,39,40 32
J70,94,113,114,115,122,123,131,133,134
J139,140,313,315,316,317,318,319,320,321
J322,323
JUP-00-00045 JUMPER 0OHM JUMPER 10m/m J33,35,36,37,38,56,57,64,65,97 19
J116,117,120,137,154,330,331,335,336
JUP-00-00052 JUMPER 0OHM JUMPER 11m/m J91,92,110,111 4
JUP-00-00046 JUMPER 0OHM JUMPER 12.5m/m J07,08,09,28,29,30,31,32,34,41 19
J42,52,53,54,55,85,86,127,150
JUP-00-00047 JUMPER 0OHM JUMPER 15m/m J14,43,66,68,69,93,101,102,118,126 12
J340,342
JUP-00-00048 JUMPER 0OHM JUMPER 17.5m/m J05,06,19,67,79,80,81,82,83 9
JUP-00-00074 JUMPER 0OHM JUMPER 19m/m J105 1
JUP-00-00049 JUMPER 0OHM JUMPER 20m/m J75,76,77,78,103,128 6
JUP-00-00075 JUMPER 0OHM JUMPER 22m/m J59,62,63,84,87,88,89,90,104,106 14
J107,108,109,112
JUP-00-00042 JUMPER 0OHM JUMPER 25m/m J22,23,24,25,26,27,58 7
ICO-00-00022 I.C P.W.M TL494CN U01 1
ICO-00-00112 I.C DUAL OPAMP (SIP-08P) NJM2068LD U101,102,103,104,105,106,107,111 8
FET-00-00023 F.E.T N-CH MOSFET FQP50N06 Q43,44,53,54 4
TRS-00-00188 TRANSISTOR AUDIO POWER NPN TIP35C Q135,235 2
TRS-00-00207 TRANSISTOR AUDIO POWER PNP TIP36C Q145,245 2
TRS-00-00111 TRANSISTOR SMALL SIGNAL NPN KTC3200GR Q140,240 2
DIO-00-00152 DIODE FAST RECOVERY YG225D2 D41,42 2
DIO-00-00048 DIODE RECTIFIER 1N5404 D01 1
DIO-00-00206 DIODE ZENER 1W 15V 1N4744A D191,291 2
RES-00-01046 RESISTOR
MOR/S 2WJ
100 OHM (3.8x11m/m) R30 1
RES-00-01269 RESISTOR
MOR/S 2WJ
330 OHM (3.8x11m/m) R191,291 2
RES-00-01041 RESISTOR
MOR/S 2WJ
680 OHM (3.8x11m/m) R162,262 2
RES-00-00895 RESISTOR WIRE WOUND 3WJ 0.1 OHM (5.5x15m/m) R160,170,260,270 4
Reference 7520a/7521a
Electrical Parts List cont'd
15
