Infinity Reference 310a Service Manual

PART NO NOMENCATURE DESCRIPTION MFR PARTS REF NO Q'TY
THS-00-00013 THERMISTOR 50K NTC RESISTOR FTD5-350 TH01 1
ELC-00-00183 CAPACITOR ELECTROLYTIC "SHL" 1000/35V (12.5x20m/m) C51,61 2
ELC-00-00603 CAPACITOR ELECTROLYTIC "SHL" 3300/35V (18x25m/m) C52,62 2
ELC-00-00727 CAPACITOR ELECTROLYTIC "WL" 2200/25V (16x25m/m) C04,05 2
SWI-00-00033 SWITCH SLIDE SWITCH JSS2319 SW101 1
SWI-00-00024 SWITCH SLIDE SWITCH JSS2219 SW102 1
VOL-00-00335 VOLUME
V12L5(9x5)G(PH2D)N15S
3B20KB x 2 VR101,103 2
VOL-00-00334 VOLUME
V12L5(9x5)G(4R)(PH2D)N15S
15C50KC x 4 VR102 1
COR-TF-00404 CORE 5(0.7X9):12(0.7X4) 37PHI ISU T01 1
COI-00-00023 INDUCTOR BAR COIL CL-300 L03 1
COI-00-00034 INDUCTOR DRUM COIL CL-500 L01,02 2
TER-00-00030 TERMINAL GOLD PLATED TM0006-01 (3P) TER01 1
TER-00-00034 TERMINAL GOLD PLATED TM0009-01 (4P) TER02 1
JAC-00-00043 RCA JACK GOLD PLATED DJB-554A RCA101 1
CON-00-00002 WAFER LWL0640-2P CLIP 1
CON-00-00033 WAFER LWL0640-3P 1ST POWER,2ND POWER 2
CON-00-00128 WAFER LAD1140-04PBK HI01 1
WIR-00-00208 WIRE ASS'Y 300m/m CHD1140-04PBK ACCESSORY 1
HOD-00-00009 FUSE HOLDER WF-9402 FH01 1
WIR-00-00017 WIRE
AWG #22 BLACK 3.2PHI RING RUG
100m/m W1 1
TUB-00-00008 TEFLON TUBE 0.7PHI 10m/m Q140,240,TH01 4
FUS-AT-00006 AUTO FUSE 30A SET1+ ASS'Y 1 2
ICO-00-00095
I.C COMPARATOR DIP-8P KIA393P U90 1
RES-00-00437
RESISTOR METAL FILM 1/5WF 1K OHM R97
1
RES-00-00402
RESISTOR METAL FILM 1/5WF 10K OHM R95
1
RES-00-00550
RESISTOR METAL FILM 1/5WF 51K OHM R96
1
RES-00-00556
RESISTOR METAL FILM 1/5WF 56K OHM R94
1
RES-00-00573
RESISTOR METAL FILM 1/5WF 68K OHM R93
1
RES-00-00635
RESISTOR CARBON FILM 1/5WJ 1M OHM R98
1
RES-00-00029
RESISTOR METAL FILM 1/2WJ 1K OHM R192,292
2
CEC-00-00005
CAPACITOR CERAMIC TUBULAR 50V 103P C91,92,93
3
CEC-00-00006
CAPACITOR CERAMIC TUBULAR 50V 104P C90
1
DIO-00-00321
LED BLUE 3PHI MS-L330CBHSK LED1,2,3 3
CON-00-00139
WAFER LAL0640-2P CLIP 1
CON-00-00140
WAFER LAL0640-3P 1ST POWER,2ND POWER 2
WIR-AS-00220
WIRE ASS'Y BK,RED CHL0640-2P(300m/m) CLIP 1
WIR-AS-00218
WIRE ASS'Y BK,RED,GREEN CHL0640-3P(300m/m) 1ST POWER 1
Reference 7520a/7521a
Electrical Parts List cont'd
16
