Infinity RS User Manual

Reference Standard (RS-4, RS-5) – Owner’s Manual
◆
7
SPECIFICATIONS
P
ERFORMANCE D ATA
D RIVE U NITS
D IMENSIONS
P ERFORMANCE D ATA
D RIVE U NITS
D IMENSIONS
RS-4
Recommended Amplifier Power: 15 ~ 175 W
Frequency Range: 38 ~ 20,000Hz
Sensitivity: (2.83 V @ 1 m) 90dB spl
Nominal Impedance: 8
Ω
Bass: 6
1
⁄2" (160 mm)
High Frequency:
1" (25 mm)
Height*, Width, Depth: 35
1
⁄2 x7
1
⁄2 x 12
1
⁄2" (902 x 190 x 318 mm)
Weight (each, net): 33.9 lb (15.2 kg)
RS-5
Recommended Amplifier Power: 15 ~ 200 W
Frequency Range: 35 ~ 20,000Hz
Sensitivity: (2.83 V @ 1 m) 92dB spl
Nominal Impedance: 8
Ω
Bass: dual 6
1
⁄2" (160 mm)
High Frequency:
1" (25 mm)
Height*, Width, Depth: 40 x 7
1
⁄2 x 12
1
⁄2" (1,016 x 190 x 318 mm)
Weight (each, net): 40.4 lb (18.1 kg)
* Add 2
1
⁄4 " (57 mm) for foot bar.
Declaration of Conformity
We, Infinity Systems A/S
Kongevejen 194B
DK-3460 Birkerød
DENMARK
declare in own responsibility, that the products described
in this owner’s manual are in compliance with technical
standards:
EN 50 081-1/2.1991
EN 50 082-1/1.1992
Steen Michaelsen
Infinity Systems A/S
Birkerød. DENMARK. 5/98
