TSS-Sub800 (120v) Electrical Parts List
Part Number
Descriptio
n
Qty
Reference Designator
PREAMP PCB
Resistors
110-16102j26-e
Resistor 1k 1/6W ±5% CF 26mm (RoHS)
4
R213,R214,R215,R254
110-16103j26-e Resistor 10k 1/6W ±5% CF 26mm (RoHS) 12
R212.R216.R217.R220.R221.R222.R225.R228.R232.
R235.R240.R248
110-16104j26-e
Resistor 100k 1/6W ±5% CF 26mm (RoHS)
2
R231.R266
110-16105j26-e
Resistor 1M 1/6W ±5% CF 26mm (RoHS)
1
R259
110-16122j26-e
Resistor 1.2K 1/6W ±5% CF 26mm (RoHS)
1
R264
110-16151j26-e
Resistor 150OHM 1/6W ±5% CF 26mm (RoHS)
1
R253
110-16154j26-e
Resistor 150k 1/6W ±5% CF 26mm (RoHS)
1
R252
110-16183j26-e
Resistor 18k 1/6W ±5% CF 26mm (RoHS)
1
R262
110-16205j26-e
Resistor 2M 1/6W ±5% CF 26mm (RoHS)
1
R257
110-16223j26-e
Resistor 22K 1/6W ±5% CF 26mm (RoHS)
3
R247.R250.R255
110-16333j26-e
Resistor 33K 1/6W ±5% CF 26mm (RoHS)
1
R249
110-16472j26-e
Resistor 4.7K 1/6W ±5% CF 26mm (RoHS)
2
R258.R260
110-16473j26-e
Resistor 47K 1/6W ±5% CF 26mm (RoHS)
2
R219.R251
110-16512j26-e
Resistor 5.1K 1/6W ±5% CF 26mm (RoHS)
3
R211.R229.R230
116-161002f26-e
Resistor 10K 1/6W ±1% MF 26mm (RoHS)
1
R7
116-161471f26-e
Resistor 1.47K 1/6W ±1% MF 26mm (RoHS)
1
R4
116-161503f26-e
Resistor 150.0K 1/6W ±1% MF 26mm (RoHS)
1
R1
116-161542f26-e
Resistor 15.4K 1/6W ±1% MF 26mm (RoHS)
2
R237.R238
116-162400f26-e
Resistor 240OHM 1/6W ±1% MF 26mm (RoHS)
1
R2
116-162871f26-e
Resistor 2.87K 1/6W ±1% MF 26mm (RoHS)
1
R234
116-163602f26-e
Resistor 36K 1/6W ±1% MF 26mm (RoHS)
1
R233
116-165361f26-e
Resistor 5.36K 1/6W ±1% MF 26mm (RoHS)
1
R6
116-1664r9f26-e
Resistor 64.9OHM 1/6W ±1% MF 26mm (RoHS)
1
R5
116-166801f26-e
Resistor 6.8K 1/6W ±1% MF 26mm (RoHS)
4
R224.R223.R226.R227
116-168251f26-e
Resistor 8.25K 1/6W ±1% MF 26mm (RoHS)
2
R3
115-h203b208-e VR 20KB*2 (RoHS) CROSSOVER 1
VR202
115-h503a104-e VR 50KA*1 (RoHS) LEVEL 1
VR201
Capacitors
129-a104j633-e
metallize Capacitor 0.1uF 63V ± 5% MSC (RoHS)
2
C5.C215
129-a153j633-e
metallize Capacitor 0.015uF 63V ± 5% MSC (RoHS)
1
C224
129-a224j633-e
metallize Capacitor 0.22uF 63V ± 5% MSC (RoHS)
1
C216
129-a274j633-e
metallize Capacitor 0.27uF 63V ± 5% MSC (RoHS)
1
C218
129-a473j633-e
metallize Capacitor 0.047uF 63V ± 5% MSC (RoHS)
1
C4
129-a474j633-e
metallize Capacitor 0.47uF 63V ± 5% MSC (RoHS)
2
C221.C222
129-a823j633-e
metallize Capacitor 0.082uF 63V ± 5% MSC (RoHS)
1
C217
130-2b221k503-e disc Capacitor 220pF 50V +/-10% Y5P (RoHS) 9
C207.C208.C210.C211.C212.C214.C220.C230.C249
130-3f104z503-e
disc Capacitor 0.1uF 50V +80/-20% Y5V (RoHS)
7
C232.C242.C244.C245.C246.C252.C254
130-sl470k503-e
disc Capacitor 47pF 50V +80/-20% SL (RoHS)
1
C229
132-103j503-e mylar Capacitor 0.01UF 50V ± 5% (RoHS) 1
C223
135-3105m50-e electrolytic 1uF 50V ±20% 85℃ (RoHS) 1
C228
135-3106m50-e electrolytic 10uF 50V ±20% 85℃ (RoHS) 8
C206.C213.C219.C231.C241.C243.C251.C253
135-3107m16-e electrolytic 100uF 16V ±20% 85℃ (RoHS) 2
C233.C234
135-3226m50-e electrolytic 22uF 50V ±20% 85℃ (RoHS) 1
C225
Semiconductors
192-027c1815gr-e transistor 2SC1815GR TOSHIBA (RoHS) NPN 1
Q201.Q206.Q207
197-031n4148-e
diode 100mA 75V SIGNAL IN4148 ROHM (RoHS)
9
D201.D202.D118.D117.D207.D206.D211.D212.D214
199-15000335-e zener diode 3.3V 1/2W 52mm （RoHS） 1
D213
190-06m4558d-e IC OPA 4558 DUAL OP-AMP 1
U203
190-16ti074cn-e I .C TL074cm st QUAD OP-AMP 2
U201.U202
195-10204hgw-e LED Red-Green 204HGW ψ3(RoHS) 1
D209
TSS-Sub800
19
