Infinity TSS-Sub800 User Manual

Part Number
Descriptio
n
Qty
Reference Designator
PREAMP PCB
Miscellaneous
162-50159201-e WIRE 2PIN White-Red 150mm 1
TO LIMIT BOARD
174-0rca326p-e RCA JACK RCA-326 3PIN(RoHS) 1
JK202
180-tms7210v-e SWITCH SLIDE 6PIN MS-7210(RoHS) PHASE 1
SW301
362-FE-00041-0LAE PCB support 11.75*8.5*12.5H(RoHS) 1
LIMITER PCB
Resistors
110-16103j26-e
Resistor 10K 1/6W ±5% CF 26mm (RoHS)
2
R109,R162
110-16102j26-e
Resistor 1K 1/6W ±5% CF 26mm (RoHS)
8
R301.R303.R304.R308.R309.R314.R340.R344
110-16183j26-e Resistor 18K 1/6W ±5% CF 26mm (RoHS) 1 R302
110-16223j26-e
Resistor 22K 1/6W ±5% CF 26mm (RoHS)
2
R310.R312
110-16273j26-e
Resistor 27K 1/6W ±5% CF 26mm (RoHS)
1
R341
110-16333j26-e
Resistor 33K 1/6W ±5% CF 26mm (RoHS)
1
R305
110-16472j26-e
Resistor 4.7K 1/6W ±5% CF 26mm (RoHS)
2
R342.R343
110-16474j26-e
Resistor 470K 1/6W ±5% CF 26mm (RoHS)
1
R307
110-16751j26-e
Resistor 750Ω 1/6W ±5% CF 26mm (RoHS)
2
R311.R313
110-16755j26-e
Resistor 7.5M 1/6W ±5% CF 26mm (RoHS)
1
R306
Capacitors
130-3f104z503-e
disc Capacitor 2700pF 100V +80%/-20%(RoHS)
2
C305.C306
132-103j503-e mylar Capacitor 0.01UF 50V ± 5% (RoHS) 2
C302.C303
135-3226m50-e electrolytic 22uF 50V ±20% 85℃(RoHS) 2
C301.C340
135-3476m25-e electrolytic 47uF 25V ±20% 85℃(RoHS) 1
C304
Semiconductors
192-027c1815gr-e transistor 2SC1815GR TOSHIBA (RoHS) NPN 2
Q301.Q302
197-031n4148-e diode 100mA 75V SIGNAL IN4148 ROHM (RoHS) 2 D301.D302
190-16tl074cn-e I .C TL074cm st QUAD OP-AMP 1
U301
Miscellaneous
162-50289001-e WIRE 7PIN 280mm UL2468 AWG26(RoHS) 1
162-80098201-e WIRE 2PIN 90mm GRAY AWG26(RoHS) 1
175-9f40hr2-e Connecter 40PIN PITCH＝2.54mm,HR2*40(RoHS) 1
POWER/MAIN PCB
Resistors
110-10821jk2-e
Resistor 820Ω 1W ±5% 10mm (RoHS)
1
R132,
110-122r2j15-e
Resistor 2.2Ω 1/2W ±5% 15mm (RoHS)
1
R127,
110-20331jk2-e Resistor 330Ω 2W ±5% 5mm(RoHS) 2 R146,R149,
113-50r10j10-e
cement Resistor 0.1Ω 5W ±5% (RoHS)
2
R121,R122,
114-03302m0-e
semi-fixed Resistor 3K 0.3W ±20% (RoHS)
1
R138,
110-14472j26-e
Resistor 4.7K 1/4W ±5% CF 26mm (RoHS)
2
R147,R150,
110-14681j26-e
Resistor 680Ω 1/4W ±5% CF 26mm (RoHS)
2
R148,R151,
110-16101j26-e Resistor 100Ω 1/6W ±5% CF 26mm (RoHS) 1 R120,
110-16102j26-e
Resistor 1K 1/6W ±5% CF 26mm (RoHS)
1
R124,
110-16103j26-e
Resistor 10K 1/6W ±5% CF 26mm (RoHS)
1
R134,
110-16105j26-e
Resistor 1M 1/6W ±5% CF 26mm (RoHS)
1
R143,
110-16123j26-e
Resistor 12K 1/6W ±5% CF 26mm (RoHS)
2
R135,R139,
110-16152j26-e
Resistor 1.5K 1/6W ±5% CF 26mm (RoHS)
2
R141,R142,
110-16153j26-e
Resistor 15K 1/6W ±5% CF 26mm (RoHS)
4
R118,R145,R152,R154,
110-16154j26-e
Resistor 150K 1/6W ±5% CF 26mm (RoHS)
1
R131,
110-16181j26-e Resistor 180Ω 1/6W ±5% CF 26mm (RoHS) 2 R111,R114,
110-16182j26-e
Resistor 1.8K 1/6W ±5% CF 26mm (RoHS)
1
R153,
TSS-Sub800
20
