Infinity TSS-Sub800 User Manual

Part Number
Descriptio
n
Qty
Reference Designator
POWER/MAIN PCB
110-16223j26-e
Resistor 22K 1/6W ±5% CF 26mm (RoHS)
3
R128,R129,R133,
110-16332j26-e
Resistor 3.3K 1/6W ±5% CF 26mm (RoHS)
3
R106,R107,R144,
110-16392j26-e
Resistor 3.9K 1/6W ±5% CF 26mm (RoHS)
2
R105,R108,
110-16393j26-e
Resistor 39K 1/6W ±5% CF 26mm (RoHS)
1
R126,
110-16470j26-e
Resistor 47Ω 1/6W ±5% CF 26mm (RoHS)
4
R112,R113,R115,R116,
110-16471j26-e
Resistor 470Ω 1/6W ±5% CF 26mm (RoHS)
1
R140,
110-16472j26-e
Resistor 4.7K 1/6W ±5% CF 26mm (RoHS)
3
R110,R125,R130,
110-16473j26-e
Resistor 47K 1/6W ±5% CF 26mm (RoHS)
1
R101,
110-16560j26-e
Resistor 56Ω 1/6W ±5% CF 26mm (RoHS)
1
R117,
110-16563j26-e
Resistor 56K 1/6W ±5% CF 26mm (RoHS)
1
R104,
110-16682j26-e
Resistor 6.8K 1/6W ±5% CF 26mm (RoHS)
1
R109,
Capacitors
132-223ja03-e
mylar Capacitor 0.022uF 100V ±5% (RoHS)
2
C123,C127,
135-3107m16-e
electrolytic cap. 100uF 16V ±20% (RoHS)
1
C110,
135-4688m50-e electrolytic cap. 6800U/50V ±20% D25X45mm (RoHS) 2
C121,C122,
130-2b102k503-e
disc Capacitor 1000P 50V ±10% (RoHS)
1
C116,
130-3f104z503-e
disc Capacitor 0.1U 50V +80/-20% (RoHS)
4
C108,C113,C115,C119,
130-3f473m503-e
disc Capacitor 0.047U 50V ±20% (RoHS)
1
C106,
132-104j503-e
mylar Capacitor 0.1U 50V ±5% (RoHS)
1
C107,
132-223ja03-e mylar Capacitor 0.022uF 100V ±5% (RoHS) 4
C124,C125,C126,C128,
135-3105m50-e electrolytic cap. 1U 50V ±20% (RoHS) 2
C105,C112,
135-3107m16-e electrolytic cap. 100uF 16V ±20% (RoHS) 3
C109,C117,C120,
135-3226m50-e electrolytic cap. 22U 50V ±20% (RoHS) 2
C114,C118,
135-3227m10-e electrolytic cap. 220U 10V ±20% (RoHS) 2
C129,C130,
135-3227m16-e electrolytic cap. 220U 16V ±20% (RoHS) 1
C111,
135-3476m25-e electrolytic cap. 47U 25V ±20% (RoHS) 1
C103,
130-sl101k503-e disc Capacitor 100P 50V SL ±10% (RoHS)
2
C139,C140,
Semiconductors
190-06m4558d-e IC OPA 4558 DUAL OP-AMP 1
U101,
192-021tip35c-e
transistor TIP35C (RoHS) NPN
1
Q107,
192-022tip36c-e
transistor TIP36C (RoHS) PNP
1
Q108,
192-027c1815gr-e
transistor 2SC1815GR TOSHIBA(RoHS) NPN
2
Q101,Q115,
192-201d882y-e
transistor KSD882Y (RoHS) PNP
1
Q117,
192-202b772y-e
transistor KSB772Y (RoHS) PNP
1
Q119,
192-991d669a-e
transistor HI-SINCERITY HSD669A (RoHS) NPN
1
Q106,
192-992b649t-e
transistor HSB649T (RoHS) PNP
1
Q105,
197-00kbl405-e diode 4A 500V KBL405 (RoHS) BRIDGE 2
D110,
197-101n4002-e diode 1N4002TB (RoHS) 2
D104,
192-027c1815gr-e
transistor 2SC1815GR TOSHIBA(RoHS) NPN
5
Q102,Q111,Q112,Q113, Q118,
192-028a1015gr-e transistor 2SA1015GR TOSHIBA(RoHS) PNP 2
Q114,Q116,
192-1572n5551-e transistor FSC 2N5551 (RoHS) NPN 2
Q103,Q109,
192-1582n5401-e
transistor FSC 2N5401 AI-PNP 350V 500mA TO-92 (RoHS) 2
Q104,Q110,
197-031n4148-e diode 100mA 75V SIGNAL 1N4148 ROHM (RoHS) 4
D101,D103,D105,D108,
199-15000335-e zener diode 3.3V 1/2W 52mm (RoHS) 1
D102,
199-15000625-e zener diode HZ6C2 RENESAS (RoHS) 2
D106,D107,
199-15001605-e zener diode HZ16-2 RENESAS (RoHS) 1
D109,
Miscellaneous
171-udhss124d-e Relay 5A 24V UDH-SS124D (RoHS) 1
RY101,
175-1c07v01-e
wire connector & base 7PIN PITCH=2.5mm (RoHS)
1 P101,
175-1d02v01-e wire connector and base 2PIN PITCH=3.96mm(RoHS) 1
P102,
175-1d03v01-e wire connector and base 3 PIN PITCH=3.96mm (RoHS
)
1
P103,
193-3m2520-e
insulator TO-3P 25x20mm (RoHS)
2
for Q107,Q108,
323-AL-00020-0LAE
HEAT SINK 65*32*31
1
351-AM03014A094-E
M3*14 machine screw (RoHS)
1
352-AM03008D040-E
￠3*8 ping screw (RoHS)
4
TSS-Sub800
21
