Infinity TSS-Sub800 User Manual

TSS-Sub800 100W Powered Sub/ Plate Amp
LINE VOLTAGE
Y
es/No Hi/Lo Line Unit Notes
US 120VAC/60Hz Yes 108-132 Vrms
Normal Operation
Europe 220-240VAC, 50-60Hz Yes 220-230 Vrms
Normal Operation
Parameter Specification Unit QA Test Limits Conditions Notes
Amp Section
Type (Class AB, D, other) AB AB
n/a 120V Model External heatsink required
Type (Class AB, D, other) G G
n/a 230V Model External heatsink required
Load Impedance (speaker) 4 Ohms
n/a Nominal
Rated Output Power 100 Watts
95 Single input driven
THD@ Rated Power 0.5 %
1 22K filter
THD @ 1 Watt 0.1 %
0.3 22K filter
DC Offset 10 mV-DC
50 @ Speaker Output
Damping factor >100 DF
100 50Hz-4 Ohms load
Measured at amplifier board speaker output
terminals, Output power 90 Watts.
Input Sensitivity
Input Frequency 50 Hz
50 Nominal Freq.
Line Input (L&R) 15.62 mVrms
±2dB To 1 Watt Single input driven, AP Zo=600 Ohms
LFE Input 10.36 mVrms
±2dB To 1 Watt LFE input driven only, AP Zo=600 Ohms
Signal to Noise
SNR-A-Weighted 100 dBA
85 rel. to rated power A-Weighting filter
SNR-unweighted 80 dBr
80 rel. to rated power 22K filter
SNR @ 1W-unweighted 60 dBr
60 rel. to 1W Output 22K filter
Residual Noise Floor 1.5 mVrms
2.5
Volume @max, using RMS reading
DMM/VOM (or A/P)
Residual Noise Floor 1
mVrms(max)
2
Volume @max, w/ A/P Swept Bandpass
Measurement (Line freq.+ harmonics)
Input Impedance
Line input L&R , LFE >10 K ohms
n/a Nominal
Filters
Low Pass (fixed or variable) 4th order --
±2dB
2nd order variable 50-150Hz + 2nd order
fix
Slope & Q dB/Octave
n/a
Subsonic filter (HPF) 2nd order fix Hz
±2dB
Slope & Q dB/Octave
n/a
Limiter (yes/no) YES --
Functional
THD at Max. Output Power 1 %
Functional
Features
LFE Input YES
Functional
Phase Switch (yes/no) YES --
Functional
Volume pot Taper (lin/log) LOG --
Functional
ATO YES
Functional
Input Configuration
Line In (L,R) L ,R --
Functional RCA inputs (L&R)
Line level in LFE LFE
Functional RCA single input
Signal Sensing (ATO)
Auto-Turn-On (yes/no) YES --
Functional
ATO Input Frequency 50 Hz
Functional
ATO Level 2 mV
Functional
@p
driven
ATO Turn-on time 5 ms
Functional
Amp connected and AC on, then input
signal applied
Auto Mute/ Turn-OFF Time 10 minutes
Functional T before muting, after signal is removed Auto turn of time (T) must be 5 > T <15
Power on Delay time 3 sec.
Functional AC Power Applied
Transients/Pops
ATO Transient 5 mV-peak
10 @ Speaker Outputs
Turn-on Transient 50 mV-peak
100 @ Speaker Outputs AC Line cycled from OFF to ON
Turn-off Transient 50 mV-peak
100 @ Speaker Outputs AC Line cycled from ON to OFF
Efficienc
y
Stand-by Input Power 14 Watts
18 @ nom. line voltage
Maximum allowable input power under
nominal Input voltage and frequency, HOT
or COLD operation.
Power Cons.@rated power 195 Watts
210 @ nom. line voltage
100 Watts @ 4 Ohms
TSS-Sub800
3
