InFocus IN126A User Manual

32
Using EZ Display
i. 4 to 1 Display: To display up to 4 computers simultaneously, click on the
location you want to display to. If you only have 2 computers, choose L (left)
or R (right). To display in full screen mode, click All. You can change the
location at any time.
ii. Mirror/Extended Display: To duplicate your computer display onto the pro-
jector, click Mirror. To extend your desktop display onto the projector, click
Extension.
iii. Video/Graphic Display: To display the best image quality, but with a slightly
slower transmission speed, click Video. To display images faster, but with
slightly less quality, click Graphic. Note: Transmission performance is deter
-
mined by your network speed.
iv. Compatibility Mode: Check the Compatibility mode box, if the projector is
having trouble displaying video from any media players.
v. Audio Streaming: To turn Audio Streaming on or off, click On or Off as
appropriate.
Note: Supported functions vary per computer’s operating system.
Projecting from Smartphones/Tablets
EZ Display is a special program to project your iOS or Android device display to a
projector through a WiFi connection. You can remotely control the projector,
decode document files, link to your dropbox account, surf the web, view photos,
display a live camera feed and transfer files wirelessly. You can even annotate
documents, webpages and photos and save them for sharing.
System Requirements
iOS
Android
Installation for Android and iOS
Search for “EZ Display” and “EZ Remote” in Google Play or App Store, then
download and install the applications. Before downloading, please make sure your
device is supported.
Start up
1 Insert the optional USB WiFi Adapter (SP-WIFIUSB-2) into the USB Type A
input.
2 Select the connection mode in the Settings > WiFi from Type-A source. See
page 29 for details.
iii
iv
v
i
ii
iOS iOS 5.1 and above
Device All iPhone model after iPhone 3GS
All iPad model after iPad 2
All iPod touch after iPod touch 4th generation
Resolution support iPhone: 480x320~1136x640
iPad: 1024x768~2048x1536
Storage At least 20MB free space needed
OS Android ICS 4.0 and above
CPU 1Ghz above
Memory 1GB DDR above
Storage At least 20MB free space needed

InFocus IN126A Specifications

General

Matrix size	0.65 \
Number of colors	1.073 billion colors
Native aspect ratio	16:10
Projection distance	- m
Projection technology	DLP
Supported aspect ratios	4:3, 5:4, 16:9, 16:10
Contrast ratio (typical)	15000:1
Screen size compatibility	- \
Projector native resolution	WXGA (1280x800)
Keystone correction, vertical	-40 - 40 °
Vertical synchronization (max)	120 kHz
Vertical synchronization (min)	24 kHz
Horizontal synchronization (max)	91 kHz
Horizontal synchronization (min)	15 kHz
Projector brightness (economic mode)	3200 ANSI lumens
Focus	Manual
Throw ratio	1.5 - 1.8:1
Zoom capability	Yes
Focal length range	- mm
Lamp power	240 W
Lamps quantity	1 lamp(s)
Light source type	Lamp
Lamp power (economic mode)	190 W
Service life of light source	3500 h
Service life of light source (economic mode)	5000 h
Full HD	No
Supported video modes	1080p, 480i, 480p, 576i, 576p, 720p
Analog signal format system	NTSC, PAL, SECAM
Audio (L/R) in	0
USB connector type	Mini-USB B, USB Type-A, USB Type-B
Serial interface type	RS-232
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
VGA (D-Sub) ports quantity	3
Optical disc player type	Not included
Internal storage capacity	2 GB
HDCP	-
Noise level	32 dB
Preset modes	Bright, Presentation
Noise level (economic mode)	30 dB
On Screen Display (OSD) languages	ARA, CHI (SIMPL), CHI (TR), CZE, DAN, DEU, DUT, ENG, ESP, FIN, FRE, HUN, ITA, KOR, NOR, POL, POR, RUM, RUS, SWE, TUR
RMS rated power	2 W
Audio formats supported	AAC, ADPCM, MP1, MP2, MP3, OGG, WMA
Image formats supported	BMP, JPG
Video formats supported	H.263, H.264, M-JPEG, MPEG1, MPEG4, WMV, XVID
Document formats supported	PDF
Placement	Ceiling
Product type	Standard throw projector
Product color	Black
Market positioning	Portable
Cable lock slot type	Kensington
Power source	AC
Power consumption (standby)	- W
Operating altitude	0 - 3048 m
Operating temperature (T-T)	0 - 40 °C
Cables included	VGA
Remote control type	IR

Weight and Dimensions

Depth	220 mm
Width	292 mm
Height	108 mm
Weight	3170 g
Package depth	305 mm
Package width	362 mm
Package height	197 mm
Package weight	3670 g
