Optional Accessories
RealCam Pan/Tilt/Zoom Camera (INF-SPTZ)
Polycom Speakerphone Adapter and Cable
(INF-POLYCBLE)
Mondopad Virtual Training (INF-VT2, INF-VT4)
Wall Mount (INF-WALLMNT2)
Floor Stand (INF-FLRSTND)
Mobile Cart (INF-MOBCART)
Accessories Shelf for INF-MOBCART or
INF-FLRSTND (INF-ACCYSHELF)
Webcam Shelf for INF-MOBCART or
INF-FLRSTND (INF-VIDSHELF)
Pro Mobile Cart in Silver
(INF-MOBCARTPRO-S)
Pro Mobile Cart in Black (INF-MOBCARTPRO-B)
Accessories Shelf for Pro Mobile Cart in
Silver (INF-ACCYSHELFPRO-S)
Accessories Shelf for Pro Mobile Cart in
Black (INF-ACCYSHELFPRO-B)
USB to HDMI Adapter (HW-USB2HDMI)
Extended warranties
Specifications
*
www.infocus.com
InFocus Corporate Headquarters
13190 SW 68th Parkway
Portland, Oregon 97223-8368, USA
Phone: (1) 503-207-4700
Toll Free: (1) 877-388-8385
Fax: (1) 503-207-4707
* Product specifications, terms, and offerings are subject to change at any time without notice.
** Keyboard, mouse and/or speaker bar may not be shipped to all countries.
©2013 InFocus Corporation. All rights reserved. Specifications are subject to change without further notice.
InFocus, The New Way to Collaborate and Mondopad are either trademarks or registered trademarks of InFocus
Corporation in the United States and other countries. All trademarks are used with permission or are for identification
purposes only and are the property of their respective companies.
InFocus_Mondopad_INF5520a_INF7021_Datasheet_EN_08OCT13.
inf5520a
inf5520a
inf7021
Size
Resolution
Refresh Rate
Viewing Angle
Technology
Display Colors
Pixel Pitch
Picture-in-Picture
Video Input Compatibility
Data Input Compatibility
Inputs
Outputs
Touch Screen
Speakers (Integrated)
Power
Mount
Display
55”
60 Hz
±89°
CCFL LCD
SBS/4 quadrant PiP
HDMI × 2, VGA (HD15 VESA), Component, S-Video,
Composite, RS232, RCA stereo audio × 2, 3.5 mm stereo
mini-jack, USB Type-B to touch screen controller board
RCA stereo audio output for sound bar or other external
A/V system
VESA MIS-F, 400 × 400 mm, M6 screws
70”
120 Hz
±176°
LED edge-lit LCD
N/A
HDMI x 2, VGA (HD15 VESA), 3.5mm stereo mini-jack,
RCA stereo audio in, 3.5mm stereo audio in,
USB Type-B to touch screen controller board
RCA audio stereo (L/R) output, 3.5mm stereo mini jack out
for sound bar
VESA standard 400 x 400mm, M6 screws
Full HD 1920 × 1080
1.07G (10-bit)
0.63 mm
Full NTSC (INF5520 only), 480i, 480p, 720p, 1080i, 1080p/24, 1080p/30, 1080p/60
VGA (640×480), SVGA (800×600), XGA (1024×768), SXGA (1280×1024), SXGA+ (1400×1050), UXGA (1600×1200),
WXGA+ (1440×900), WSXGA+ (1680×1050), WXGA (1280×800), WUXGA (1920×1200)
Edge-to-edge quad camera multi-touch system with support for 5 point gestures and Windows 8
Stereo 7W × 2
AC 100 to 240V, 50/60Hz
inf7021
Processor
Memory
Hard Drive
LAN (2×)
Wi-Fi
Input Connections
Output Connections
Operating System
Included Software
PC
USB Type-A × 6 (4 on side of display,
2 on PC (1 used by camera)), Ethernet (RJ45 × 2)
USB Type-A x 7 (4 on side of display, 1 on top of display
(used by camera), 2 on PC), Ethernet (RJ45 × 2)
Intel
®
Core i5-2520m, QM67 chipset with support for AMT 7.1
4 GB of DDR3
SSD 120GB
802.3 10/100/1000 Base-T with Wake on LAN
Dual band 802.11 a/b/g/n MIMO PCIe half mini card, 2.4 GHz with Intel, AMT support
Optional USB 2.0 to HDMI adapter (for display out)
Windows 7 Pro 64bit, compatible with Windows 8
Microsoft Office Home & Business 32bit, Mondopad interface software
Camera
Resolution: 1280 × 720
Frame rate: 22 fps at HD with H.264+YUV (2-way)
Lens and Field of View: F/2.0, 3P Lens; FOV(D) 56.8° in HD mode, FOV(D) 50° in
VGA mode 1.0× zoom, FOV(D) 30° in VGA mode 1.6× zoom
Audio support: 4 built-in Unidirectional microphones
Interface: USB 2.0 High Speed
Focus: Auto focus
Tilt: Manual up/down and left/right ±40°
Power via USB
Soundbar
Power: 100 – 240 volts AC, 50 – 60Hz
Speaker Drivers (L&R Channel): Two 3" and one 3/4" Aluminum Neodymium
Tweeter (per side)
Power Output (RMS): 25 watts/channel @ 1% THD, 1KHz, 2-channels drive, 70
watts total system PEAK
Frequency Response: 90 Hz to 20 KHz
System INF5520a INF7021
Product Weight 134.4 lbs / 61 kg 170 lbs / 77.1 kg
Shipping Weight
(monitor, PC & camera) 136 lbs / 61.7 kg 173 lbs / 78.5 kg
(sound bar) 14.3 lbs / 6.5 kg 17.4 lbs / 7.9 kg
(feet) 9.3 lbs / 4.2 kg Not included
Product Dimensions (W x D x H)
INF5520a: 53 x 5.5 x 38.3 in / 1346 x 140 x 973 mm
INF7021: 65.7 x 4 x 45 in / 1669 x 102 x 1143 mm
Shipping Dimensions: INF5520a
Monitor, PC & camera: 58.7 x 13.9 x 38.4 in / 1490 x 352 x 975 mm
Sound bar: 57.5 x 7.1 x 5.7 in / 1430 x 180 x 145 mm
Feet: 22.1 x 5.3 x 15.9 in / 560 x 135 x 405 mm
Shipping Dimensions: INF7021
Monitor, PC & camera: 73 x 10.5 x 49 in / 1854 x 267 x 1245 mm
Sound bar: 30.4 x 12.3 x 6.7 in / 772 x 313 x 169 mm
Accessories Included**: Wireless keyboard (where allowed), wireless mouse
(where allowed), stylus, VGA cable, USB cable, security screws, security screw
removal tool, power cord, remote, quick setup guide, sound bar assembly,
camera assembly, foot assembly (feet not inlcuded with INF7021)
Warranty: 1 year limited, extended warranties available
Operating Temperature: 41 to 95°F at 0 to 10K ft / 5 to 35°C at 0 to 3,048 m
Noise: <40dBA @ 77°F / 25°C
Energy Star: 5.1 for display and PC
Approvals for INF5520a: United States (FCC, UL), Europe (CE), Australia (RCM),
Brazil (ANATEL), Canada (IC, FCC, cUL), Chile (SUBTEL), China (CCC, CMIT),
Columbia, Costa Rica, India (WPC), Indonesia (PLG), Malaysia (SIRM), Mexico
(NOM, SCT, Energy Consumption label), New Zealand (C-tick), Panama, Peru
(MTC), Puerto Rico (FCC, UL), Saudi Arabia (SASO, CITC), Singapore (PSB, IDA),
Taiwan (BMSI, NCC), United Arab Emirates (TRA)
Approvals for INF7021: United States (FCC)
Interface Languages: English, German, French, Italian, Spanish, Simplified
Chinese, Traditional Chinese, Korean, Vietnamese, Japanese, Malay, Bahasa
