InFocus LP540 Technical Specifications

THE INFOCUS COMMITMENT
InFocus Corporation’s dedication to quality and customer satisfaction is reflected in service options that will bring you a greater return on your
investment. InFocus projectors come with a standard 2-year limited factor y warranty, including parts and labour and a 90-day lamp replacement
warranty. Our customer suppor t offers you premium service and convenience, whatever your needs.
For service programme details in your region, please visit www.infocus.com/service/service_offerings
www.infocus.com
InFocus Corporate Headquarters:
27700B SW Parkway Avenue • Wilsonville, Oregon 97070-9215, USA
Phone: (1) 503-685-8888 • 1-800-294-6400 • Fax: 503-685-8887
In Europe: InFocus International BV
Strawinskylaan 585
•
1077 XX Amsterdam
•
The Netherlands
Phone: (31) 20 5792000
•
Fax: (31) 20 5792999
Freephone: 008000 4636287 (008000 INFOCUS)
In Asia: InFocus ASA
238A Thomson Road • #18-01/04 Novena Square
Singapore 307684 • Phone: (65) 6334-9005 • Fax: (65) 6333-4525
InFocus, LP, and LiteShow are registered trademarks and ProjectorNet and ProjectAbility are trademarks of InFocus
Corporation. All other trademarks are used with permission or are for identification purposes only and are the property of
their respective companies. ©2003 InFocus Corporation. All rights reser ved. 590-0711-00. LP540_DS_UK2_V00.qxd.
11/2003
OPTIONAL ACCESSORIES
HW-PRESENTER Presenter Remote
HW-PRESENTER-RF Presenter RF Remote
HW-CONDUCTOR+ Conductor Plus Remote
LP-LITESHOW Liteshow
®
Wireless
Connection
SP-DVI-D Digital Computer Cable
SP-M1-ADPT M1 to Component Adaptor
SW-PN2-1CD ProjectorNet
™
Software
CA-ATA-019 ATA Roller Case
CA-C230 Organiser Soft Case
SP-CEIL-011 Ceiling Mount Kit
SP-LOCK-B PC Guardian Projector
Cable Lock
A650 127 cm/50" Portable
Projection Screen
HW-DLXSCRN 152 cm/60" Deluxe Insta-
Theatre Screen
HW-WALLSCR84 213 cm/84" Pull-Down
Screen
SP-LAMP-017 Replacement Lamp
Ships Standard With
•Soft Carry Case
•Navigator Remote
• Colour-coded cable straps
•M1-A Computer cable with USB Mouse
•3.5 mm computer audio cable
• RCA audio/video cable
• Power cord
•User Manual, Quick Start Card and CD
—
TECHNICAL SPECIFICATIONS
†
Native Resolution • XGA 1024 x 768
Display Technology • 3 x .79" polysilicon TFT LCD, active-matrix non-MLA
Computer Input Sources • Computer 1 (M1-DA), Audio (3.5 mm Stereo)
Wireless Connectivity • Yes with optional LiteShow
®
module
Networking • Yes with optional ProjectorNet
™
software and module
Video Input Sources • Video 1 (S-Video), Video 2 (Composite RCA), Audio (RCA Stereo)
Control Input Sources • RS232, USB
Output Sources • Variable Stereo Audio (RCA), Monitor Out (VESA)
Computer Compatibility • SXGA+, SXGA, XGA, SVGA, VGA, Macintosh
®
, HDTV 1080i, 1080p, 720p, 480p, 576p
Video Compatibility • Full NTSC, PAL, SECAM, HDTV 1080i, 1080p, 720p, 480p
Brightness • 1700 max ANSI lumens
Brightness Uniformity • 75%
Contrast Ratio • 400:1
Number of Colours • 16.7 million
H-Synch Range • 16-110 kHz
V-Synch Range • 50-85 Hz
Dot Clock • 135 MHz
Automatic Ceiling Detection • Yes
Automatic Ver tical Keystone Correction • Yes
Digital Keystone Correction (Vertical) • +/- 25°; data/video
Projection Lens • Zoom lens with manual focus and manual zoom adjust
Zoom Ratio • 1.2:1
Throw Ratio • 1.6:1-1.9:1 (D:W)
Projection Distance • 1.5 m-10.0 m (5'-32.8')
Image Offset Ratio (%) • 95 ± 5 %
Aspect Ratio • 4:3 Native Aspect Ratio
Image size (diagonal) • 1.0 m to greater than 7.5 m / 40" to greater than 300"
Projection Methods • Front, rear and ceiling
Projector Audio • 2.0 watt stereo
Projector Interface • Interactive LCD Display or Menu system
Projector Interface Languages • English, Spanish, French, German, Japanese, Korean, Por tuguese, Italian,
Norwegian, Russian, Chinese Simple, Chinese Traditional
Projector Control • Menu, Keypad, ProjectorManager
™
, RS232
Mouse Control • USB
Lamp • 170 W UHP / 2000 hours*
Dimensions • 10.3 cm (H) x 26.0 (L) cm x 29.4 cm (W) /4.1" x 10.3" x 11.6"
Weight • 3.4 kg / 7.5 lbs
Power Consumption • 260 watts
Power Supply • 85V-240V at 50-60 Hz
Operating Temperature • 10°-35°C at sea level (0'-10,000'), 50°-95°F
Audible Noise • 34dB
Approvals • FCC A (US/Canada), UL & cUL (US/Canada), GOST (Russia), TUV GS (Germany),
CCC (China), IRAM (Argentina), NOM (Mexico), MIC (Korea), C-Tick (Australia)
Lamp Warranty • 90 days or 500 hours, whichever comes first
Product Warranty • 2 years par ts and labour
Accessory Warranty • 1 year
* Actual lamp life may vary based on the ambient environment. Conditions that may affect lamp life include temperature, altitude,
rapidly switching the projector on and off and switching between standard and low power modes.
†InFocus reserves the right to alter product offerings and specifications at any time without notice.
Contact InFocus or your dealer today.

InFocus LP540 Specifications

Display

native resolution	XGA 1024 x 768
brightness	1700 max ANSI lumens
brightness uniformity	75%
contrast ratio	400:1
number of colours	16.7 million

Projection

projection distance	1.5 m-10.0 m (5'-32.8')
image size (diagonal)	1.0 m to greater than 7.5 m / 40" to greater than 300"
aspect ratio	4:3 Native Aspect Ratio
zoom ratio	1.2:1
throw ratio	1.6:1-1.9:1 (D:W)

Lamp

lamp type	170 W UHP
lamp life	2000 hours*
lamp warranty	90 days or 500 hours, whichever comes first

Power

power consumption	260 watts
power supply	85V-240V at 50-60 Hz

Operating Environment

operating temperature	10°-35°C at sea level (0'-10, 000'), 50°-95°F
audible noise	34dB

Dimensions and Weight

dimensions	10.3 cm (H) x 26.0 (L) cm x 29.4 cm (W) /4.1" x 10.3" x 11.6"
weight	3.4 kg / 7.5 lbs
