InFocus VHD-V61U - Main Unit Overview

10
1xRS-485: 2pin phoenix port, Max Distance: 1200m,
Protocol: VISCA/Pelco-D/Pelco-P
Power Connector
JEITA type (DC IN 12V)
Generic Specification
Input Voltage
DC 12V
Current Consumption
1.0A (Max)
Operating Temperature
-5°C ~ 40°C
Storage Temperature
-20°C ~ 60°C
Power Consumption
12W (Max)
Size
169mm x 142mm x 164mm
Net Weight
1.35Kg
Main Unit
1. Line in Interface 7. POWER switch
2. CVBS Interface 8. DC IN 12V jack
3. System select switch 9. HDMI interface
4. RS485 Interface 10. USB2.0
5. RS232 IN Interface 11. USB3.0
6. RS232 out Interface 12. Rj45 interface
