Voltage
Model No.
CS18528
CS18528S
(SAA Plug)
CS18528-8
(BS Plug)
CS18528-6
(ISRAEL Plug)
CS18528-4
UCS18528CS18528-6E
220-240V~50/60Hz
Power rating
1400 W
Idle speed
4800/min
Cutting depth at 45°
45 mm
Cutting depth at 90°
65 mm
Totally insulated
II/
Saw blade
185 mm
110-120V~50/60Hz
1400 W
4800/min
45mm(1-3/4″)
65mm(2-9/16″)
II/
185mm(7-1/4″)
1. Description(Fig.1+Fig.2)
1. Handle
2. On/Off switch
3. Interlock button for On/Off switch
4. Locking lever for cutting depth setting
5.
Power cable
6. Hinged guard hood
7 . Flange
8 . Saw blade
9 . Parallel stop
10. Lock screw for the parallel stop
11. Lock screw for mitre cuts
12. Additional handle
Please read these instructions carefully and pay
particular attention to the safety regulations. Keep
the instructions together with the circular saw.
2. Technical data
Voltage
Model No.
CS18568 CS185682
CS18568S
(INMENTRO Plug)(INMENTRO Plug)
CS18568-8
(BS Plug)
CS18568-6
(ISRAEL Plug)
220-240V~50/60Hz
Power rating 1600 W
Idle speed 5000/min
Cutting depth at 45° 45 mm
Cutting depth at 90° 65 mm
Totally insulated II/
Saw blade 185 mm
220-240V~50/60Hz
1400 W
4800/min
45 mm
65 mm
II/
185 mm
Voltage
Model No.
Power rating
Idle speed
Cutting depth at 45°
Cutting depth at 90°
Totally insulated
Saw blade
3. Applications
The hand-held circular saw is designed for sawing
straight cuts in wood, in materials similar to wood,
and in plastics.
4. Safety regulations
The corresponding safety information can be found
in the enclosed booklet.
UCS18528-9
127V~60Hz
CS18528-9
1400 W
4800/min
45mm(1-3/4″)
65mm(2-9/16″)
II/
185mm(7-1/4″)
220-240V~50/60Hz
1400 W
4800/min
45 mm
65 mm
II/
185 mm
Voltage
Model No.
Power rating
Idle speed
Cutting depth at 45°
Cutting depth at 90°
Totally insulated
Saw blade
UCS18568
110-120V~50/60Hz
1600 W
5000/min
45mm(1-3/4″)
65mm(2-9/16″)
II/
185mm(7-1/4″)
Voltage
Model No.
Power rating
Idle speed
Cutting depth at 45°
Cutting depth at 90°
Totally insulated
Saw blade
The hinged guard hood is not to be wedged in
the retracted guard hood when sawing.
5. Working with the hand-held
circular saw
Always hold the circular saw firmly.
The hinged guard hood will be pushed back
automatically by the workpiece.
Never apply force! Advance the circular saw
gently and steadily.
The off-cut piece should be to the right of the
circular saw so that the wide part of the base
plate is supported over its entire surface.
When sawing along a marked line, guide the
circular saw along the corresponding groove.
Clamp small pieces of wood securely before
sawing. Never hold them in your hand.
Always observe the safety regulations! Wear
goggles!
Do not use defective saw blades or blades with
cracks or flaws.
Do not use flanges or flange nuts with a hole
which is larger or smaller than that of the saw
blade used.
Do not try to stop the saw blade with your hand
or by applying pressure to the side of the blade.
The hinged guard must not jam and must return
to its original position once work is completed.
Before plugging in the circular saw, check that
the hinged guard is functioning properly.
Before each use, always check that the safety
devices - the hinged guard, splitter, flanges and
adjustment devices - are functioning properly and
have been adjusted and secured correctly.
You can connect a suitable dust extractor to the
guard hood. Check that the dust extractor is fitted
securely and properly.
(IRAM Plug)
11|English
