47
INGENIA IG3T Cod. 420120239 REV. 1.1
The speaker is supplied equipped with a pre-installed fuse designed to
operate within the 220-240 V range. If the system must operate within the
100-120 V range:
1. Disconnect all connections, including the power supply one
2. Wait 5 minutes.
3. Replace the fuse with the one included in the package for the 100-120 V range.
4. Only use the provided power cord.
2. FIRST SWITCH-ON
PACKAGE CONTENTS
INSTALLATION
CONNECTING THE INPUTS
Open the package and check that the INGENIA IG3T speaker packaging contains all the items included in the
supply. The packaging includes:
• power cord with connector Neutrik® TRUE powerCON TRUE1®
• INGENIA IG3T
• quick start and warranty-related documents
• fuse to be installed if the system is to operate within the 100-120V range
ATTENTION!
MIXER / LINE MICROPHONE
English
