03 PRODUCT DIAGRAM
2
24Vac /1A Power
Adaptor Port
Rain Sensor Port
Zone1~6
Valve Ports
Master Valve Port
Common Port
Indicators of Wi-Fi
Connection and
Irrigation Zone
Wi-Fi Button
Setting Button
Start/Stop Button
