Chapter 3: Receiver
WARNING! The receiver must NOT be opened by any other than a qualified installer. Make sure to turn the
electricity off before opening the receiver.
Technical Data
Receiver
Frequency
433.0525~434.7775MHz
Modulation Method
4GFSK
Sensitivity
-112dBm@baud 1.2K bps
Control System
PLL
Antenna impedance
50 ohms
Typical response time for commands
50mS ~ 100mS
Power Supply (AC)/Power Consumption
24 ~ 240VAC, 50/60Hz (8.3 Watts)
Power Supply (DC)/Power Consumption
24 ~ 160VDC (12.8 Watts)
Antenna
External
Standby power
<30mA @ 120VAC
Operating and storage temperature
-4°F~131°F/-40°F~149°F
Protection degree
IP 65
Dimensions
7.46” x 7.22” x 2.52”
Weigh
3.95 Lbs.
Housing material
PA6 (30% Glass Filled)
