Installation Overview
3
Unit Installation
Overview
L N
1
2
3
4
5
MC MC
6
7
8
Install the indoor unit
(Page 7)
INSTALLATION ORDER
Install the outdoor unit
(Page 11)
Install the drainpipe
(Page 14)
Evacuate the refrigeration system
(Page 23)
Connect the wires
(Page 19)
Connect the refrigerant pipes
(Page 16)
Install the front panel
(Page 25)
Perform a test run
(Page 27)
