Indoor Unit Installation
4
Indoor Unit Parts
(within indoor unit)
Drain pipe
Air outlet
Air inlet
Display panel
Front grille
Louver
Refrigerant pipe
Fig. 4.1
Safety Precautions
WARNING
• Securely install the indoor unit on a structure that
can sustain its weight. If the structure is too weak
the unit may fall causing personal injury, unit and
property damage or death.
• Install the indoor unit at a height of more than
2.5m (8’) above the floor.
• DO NOT install the indoor unit in the bathroom or
laundry room as excessive moisture can short the
unit and corrode the wiring.
CAUTION
• Install the indoor and outdoor units, cables and
wires at least 1m (3.2’) from televisions or radios
to prevent static or image distortion. Depending
on the appliances, a 1m (3.2’) distance may not be
sufficient.
• If the indoor unit is installed on a metal part of the
building, it must be electrically grounded.
Indoor Unit
Installation
