SERVICE MANUAL
PET12C1PR1
AIR CONDITIONER

Questions and Answers

  • J
    Jamie Young DVMAug 1, 2025
    Why is my innovair PET12C1PR1 not cool enough?
    • J
      Janet LeAug 1, 2025
      If your innovair Air Conditioner isn't cooling sufficiently, several factors could be at play. First, ensure all windows and doors in the room are completely closed. Heat sources within the room can also impact cooling efficiency, so remove them if possible. Check that the exhaust air duct is properly connected and not blocked, allowing it to function correctly. Also, verify that the temperature setting isn't too high; decreasing it may resolve the issue. Lastly, a blocked air filter can hinder performance, so clean the air filter to ensure optimal airflow.
  • E
    edward56Aug 6, 2025
    What to do if innovair PET12C1PR1 does not start?
    • H
      Hunter MasonAug 6, 2025
      Your innovair Air Conditioner might fail to start for a couple of reasons. If 'P1' appears in the display window, it indicates that you need to drain the water from the bottom tray. Alternatively, if you're in cooling mode and the room temperature is lower than the set temperature, the unit won't start. In this case, reset the temperature to a lower setting.
  • E
    Emily ZimmermanAug 13, 2025
    Why is my innovair PET12C1PR1 Air Conditioner so noisy?
    • B
      Brett OlsonAug 13, 2025
      If your innovair Air Conditioner is making excessive noise or vibrating, it's likely due to the unit not being placed on a level surface. To resolve this, position the air conditioner on a flat, level ground if possible.
  • G
    George CookAug 19, 2025
    What to do if innovair PET12C1PR1 power shut off at Heating mode?
    • E
      Elizabeth JohnsonAug 19, 2025
      If your innovair Air Conditioner shuts off in heating mode, it's likely due to the automatic overheat protection function. When the air outlet temperature exceeds 70°C / 158°F, the device will automatically stop. To resume operation, switch the unit on again after it has cooled down.
  • M
    Michelle ReyesAug 26, 2025
    Why does my innovair PET12C1PR1 Air Conditioner make a gurgling sound?
    • K
      Kari ValenzuelaAug 26, 2025
      The gurgling sound you hear in your innovair Air Conditioner is normal. It comes from the flowing of the refrigerant inside the unit.

Summary

1. Precautions

1.1 Safety Precautions

Instructions to prevent injury and property damage.

1.2 Warnings and Cautions

Covers installation, electrical, and operational hazards.

2. Functions and Control Panel

5. Wiring Diagram

6. Electronic Functions

7. Installation Details

7.2 Care and Maintenance

8. Basic Test Procedure

8.1 Defective Compressor Diagnosis

Methods to identify and test compressor faults.

Compressor Wiring and Ground Tests

Procedures for testing compressor wiring continuity and grounding.

Checking Compressor Efficiency

Assessing compressor performance and identifying inefficiency.

Compressor Terminal Overload Tests

Testing external and internal compressor overload protection.

8.2 Sealed Refrigeration System Repairs

Required Equipment for System Repairs

Lists necessary tools and equipment for refrigerant system service.

Hermetic Compressor Replacement

Step-by-step guide for replacing hermetic compressors.

Compressor Motor Burnout Procedures

Special steps for handling compressor motor burnout issues.

Refrigerant Charge Procedure

Correct methods for charging refrigerant into the system.

8.3 Fan Motor

8.4 Capacitor

10. Troubleshooting

innovair PET12C1PR1 Specifications

General IconGeneral
RefrigerantR410A
Voltage220-240V
Noise Level (Indoor Unit)42 dB(A)
Cooling Capacity12, 000 BTU/h
Power Supply1-phase, 50Hz
Air Flow (High Speed)550 m3/h
