UN-BOX YOUR OXO!
UN-BOX YOUR OXO!
While folded, stand the OXO on kickstand.
Push down rear end of OXO to release the SNAP LOCK and raise up the
steering rod
Set the handle bar in place
Use the hex key (4m)
Are you ready to set your OXO free?
Please follow these instructions:
Fasten the RED lever
Adjust the brakes angle
according to your height.
A good indication for your suited
angle is that your wrists are
straight when you ride
4m
Connect the rear mudguard
Use hex key (5m)
When folding repeat steps
2, 3 and 4 in reverse order
and then simply snap the
steering rod into place
If the SNAP LOCK of your OXO
is too loose / tight, you can
ne-tune it by adjusting the
height of the locking hook.
Use hex key (2.5m)
1
2
7
5
3
4
8
6
9
5m
Adjust the tightening of the lever
by the front tension adjuster
Fix safety lock rubber band
3
2
4
