Inovance IT7070T User Manual

‑17‑
No. Name Function Description No. Name Function Description
1
Power
port
24 VDC power input
(delivered together with a
power terminal used to
connect to this power
port)
6
Mini USB
port
Slave port of USB
communication used for
user program
downloading and
commissioning through
PC
2
DB9
male
Communication port
between HMI and
peripherals
Built‑in COM1, COM2 and
COM3 serial
communication ports
COM1: RS422 or RS485
COM2: RS232
COM3: RS232
Note:
1. IT7070T only includes
built‑in COM1 and COM2.
2: IT7070S only includes
built‑in COM1.
7
Firmware
upgrade
port
For firmware upgrade
Note: Firmware upgrade
port is not available in
‑BG1 model.
3
Ethernet
port
Ethernet communication
port (RJ45) used to access
the PLC with LAN port
Note: Ethernet port is not
available in IT7070S/
IT7070T.
8
Micro SD
card
interface
Mounts a Micro SD card
for data read/write and
project file download
Note: Micro SD card
interface is not available
in IT7070S/IT7070T.
